Load Integral [%]; Load Cmp Input; Cu:ai7, Cu:ai8, Cu:ai9, Aio:ia1, Aio:ai2, Aio:ai3, Aio:ai4]; Load Cmp Off - ComAp InteliDrive Lite Reference Manual

Default: 0
7.6.9 Load Integral
This setpoint is giving Load limit integration factor.
Step: 0.1
Range: 0.0% - +100.0%
Default: 0

7.6.10 Load CMP Input

This setpoint is for Load limit comparetor with hysteresis analog input selection. Source can be
adjusted from controller RPM pick-up, ECU, analog inputs or from extension module inputs.
Default state: RPM

7.6.11 Load CMP Off

Limit to close LBO LoadSwitch
Step: 1
Range: -10000 - +10000
Default: 95

7.6.12 Load CMP On

Limit to open LBO LoadSwitch
Step: 1
Range: -10000 - +10000
Default: 90
7.7

Engine protect

7.7.1 Eng prot del
During the start of the engine, some engine protections have to be blocked (e.g. Oil pressure). The
protections are unblocked after the Protection del time. The time starts after reaching Start RPM.
Step: 1s
Range: 0 - 300s
Default: 5s
InteliDrive Lite, SW version 1.9
ID-FLX-Lite-1.9r1 Reference Guide.pdf, ©ComAp – August 2015
[%]
[RPM, ECU:Load,
CU:AI4, CU:AI5, CU:AI6, CU:AI7, CU:AI8,
CU:AI9, AIO:IA1, AIO:AI2, AIO:AI3, AIO:AI4]
[s]
CU:AI1, CU:AI2, CU:AI3,
91
