- Page 1 WBASG Kit in S tA l l A t i o n m A nu A l IMPORTANT! A Radio “Re-Flash” Is Strongly Encouraged Before Proceeding. Please Read Manual For More Information...
- Page 2 Ultra Classic® models. We want your new kit to work as well as it was designed to, so if you have any questions or concerns, please email: tech@hogtunes.com or call us during regular business hours at 705-719-6361 (EST). If you still need help, please consider a professional installation by your dealer.
-
Page 3: Before Getting Started
After considerable testing, we have concluded that nothing works as well as the factory antenna which is why Wild Boar Audio and Hogtunes do not offer in fairing antennas. -
Page 4: Speaker Installation
se ct io n 1 Sp eA Ker i nS t A llA t i on Step #1: Remove the bikes seat, and undo the main (+ and -) connectors from the battery. Remove the outer fairing/headlamp assembly and set aside. Refer to a service manual if you need help with this. - Page 5 Step #3: Installing the Speaker: With the cabinet removed from the bike, undo the 4 screws that hold the factory speaker to the cabinet and put these screws aside. Pull the factory speaker away from the cabinet and carefully take off each speaker wire by un-doing one at a time.
-
Page 6: Amplifier Installation
se cti on 2 A m pli fi e r i n S t A llA t i on Step #1: Over top of the radio, pull up to release each wire harness from the black plate via the factory “Christmas Tree”... - Page 7 white plug and insert it into the “audio in” on the side of the amp. Sit the amp on top of the silver plate so when standing in front of the bike, the power harness is on your left (aka the BRAKE SIDE of the bike). Re-install the amp to the plate using the four screws removed earlier.
- Page 8 Figure 1.3 - Stock Harness and Amplifier’s Harnesses Passing From Fairing To Just In Front Of Tank (Arrow A). Cable Tying the 2 Amp Harnesses To The Main Bike Harness Just In Front Of The Tank (Arrow B) Allows The Amp Harnesses To Go Up Towards The Tank’s Chrome Console Easier And Makes For a Cleaner Install.
-
Page 9: S Y St E M Ad J U S T Ment
sec tio n 3 S y St e m Ad j u S t ment This section is VITAL to the correct operation of the system, please make sure you read and understand it, or contact us! Step #1: In order for the system to work properly you will need to have the correct “flash”... - Page 10 Please Note: Having your radio re-flashed to “4 Speakers No Amplifier” in all cases is the preferred condition. With this flash, and the amp set to “Position A” You will get the best volume and your radio’s AVC (Automatic Volume Control) will work. Position “B”...
- Page 11 Please contact Hogtunes head office for all warranty claims. Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be equivalent) at Hogtunes sole discretion. Hogtunes/Wild Boar Audio’s complete warranty policy is available on our website at www.hogtunes.com...
- Page 12 Original Equipment, which can be a distraction to the rider and/or passenger. Please use caution when adjusting or playing your stereo at high volume, especially in traffic. You are a valued customer so please: Ride Alert Arrive Alive! www.wildboaraudio.com www.hogtunes.com...
