- Page 1 XM-4440 FID Dumbbell B Owner’s Manual Read all precautions and instructions in this manual before using this equipment.
-
Page 2: Table Of Contents
Table of Contents Before You Begin Important Safety Information Assembly Exploded View Parts List... -
Page 3: Before You Begin
CALL 1-800-719-4605 Monday-Friday 8:30 a.m.-5:00 p.m. XMARK FITNESS SERIES (Central Standard Time) MODEL: XM-4440 For Warranty information please visit www.xmarkfitness.com. When calling please have the following product information available: Model Name : XM-4440 Date Mfg.: Serial # Model Name Decal Location... -
Page 4: Important Safety Information
Important Safety Information NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. Prior to assembly, remove components from the box and verify that all the listed parts were supplied. SAFETY INFORMATION WARNING! Before using this unit or starting any exercise program, consult your physician. This is especially important for persons over the age of 35 and/or persons with pre- existing health problems. -
Page 5: Assembly
Assembly Attach the Front Leg (1) to the Frame (2) with two M10 x 20mm Bolts (30) and two M10 Locknuts (20); do not tighten the Bolts yet. Insert the Rear Stabilizer (5) into the Frame (2) securing with four the M10 x 20mm Bolts (30) and four M10 Washers (31);... - Page 6 Assembly Push four Spacers (17) into the Backrest Supports (7). Pull the Seat Knob (12), insert the Seat Bracket (3) into slot in the Frame (2), and release Seat Knob into an adjustment hole in the Seat Bracket. 28 27 Attach the Backrest Supports (7) and Seat Frames (4) to the Frame (2) with an M12 x 180 mm Bolt (26), one Plastic Sleeve (8),two M12...
- Page 7 (7) with eight M6 Washers (24) and eight M6 x 40mm Screws (25). See step 3. Tighten the eight M6 x 40mm Bolts (22). Make sure that all parts are properly tightened before you use the weight bench. Congratulations!! You have completed assembly of your XM-4440!
-
Page 8: Exploded View
