Capella - 2+2 Sliding Robe
Assembly Instructions -
Dimensions
Width - 120cm
Depth - 59.5cm
Height - 181cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
268/1647
259/4071
262/0488
244/0273
MADE IN
BRITAIN
Issue 2 - 28/03/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Capella 268/1647
Summary of Contents for Argos Capella 268/1647
- Page 1 Capella - 2+2 Sliding Robe Assembly Instructions - 268/1647 Please keep for future reference 259/4071 262/0488 244/0273 Dimensions Width - 120cm Depth - 59.5cm MADE IN Height - 181cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 2 - 28/03/14...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 79kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side Large Divider (D2710A) (D2711A) (D2712A) (1808 x 592mm) (1808 x 592mm) (1246 x 496mm) Rail...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
-
Page 5: Table Of Contents
If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Note: The arrow on the Note: Due to the manufacturing process, locking nut must point the holes for the locking nut can be on towards the hole in the Prepare the 4 top either surface of the drawer sides. -
Page 6: Prepare The 4 Top
Assembly Instructions Step 4 Prepare the top drawer front Screw 4 metal dowels into the top drawer front Note: Tighten the metal dowels up fully against the panels. Step 5 Fit the drawer front Lower the 2 top drawer assemblies down onto the back of the top drawer front Use a screwdriver to... -
Page 7: Top Left Drawer Sides
Assembly Instructions Step 7 Runners must be pushed up against Fit the runners and the drawer front the wedgefixes Turn the top drawer assembly over. Fit a runner the bottom edge of the top left drawer side as shown, making sure that it is pushed up against the back of the top drawer front... -
Page 8: Turn The Assemblies Over
Assembly Instructions Step 8 Note: The arrow on the locking nut must point towards the hole in the Prepare the 4 bottom edge of the panel. drawer sides Insert a small locking into the hole shown on each of the 2 botom left drawer sides and 2 bottom right drawer sides... - Page 9 Assembly Instructions Step 11 Prepare the bottom drawer front Screw 4 metal dowels into the bottom drawer front Step 12 Fit the drawer front Lower the 2 bottom drawer assemblies down onto the back of the bottom drawer front Use a screwdriver to tighten the 4 small locking nuts fitted to...
- Page 10 Assembly Instructions Runners must be Step 14 pushed up against the drawer front Fit the runners and the wedgefixes Turn the bottom drawer assembly over. Fit a runner the bottom edge of the bottom left drawer side , as shown, making sure that it is pushed up against the back of the bottom drawer front...
- Page 11 Assembly Instructions Step 15 Prepare the top and base Place 2 plastic tracks down onto each of the and base panels, making sure that they are flush with the edges of the panel. Gently tap along the length of the plastic Finished tracks until they are...
- Page 12 Assembly Instructions Step 16 Finish preparing the base Take 1 of the top/base panels you have just prepared and screw in 2 Finished metal dowels front edge This will now be used as the base. Step 17 Prepare the large divider Finished Push a rail holder...
- Page 13 Assembly Instructions Step 18 Fit top and base to the divider Attach the top base to the large divider using 4 screws Base Note: The plastic tracks must be on the inside surfaces of the top and base Note: The base is the one that has the 2 metal dowels.
- Page 14 Assembly Instructions Step 20 screw screw screw Prepare the right side Fit 2 runners the right side The 1st screw uses the 1st hole in from the front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 15 Assembly Instructions Step 21 Finished top edge Fit a back rail Note: Support the back rail until the Push a back rail right side has been onto the large divider fitted in the next step. Tap 2 double metal dowels through the large divider and into...
- Page 16 Assembly Instructions Step 23 Fit the mushroom head pins Tap 2 mushroom head pins into the holes on the outside of the right side into the top base Use a screwdriver to tighten the 2 large locking nuts fitted to the top and base Step 24...
- Page 17 Assembly Instructions Step 25 screw screw screw Prepare the small divider Fit 2 runners the small divider Finished The 1st screw uses front edge the 1st hole in from the front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 18 Assembly Instructions Step 26 screw screw screw Prepare the left side Fit 2 runners the left side The 1st screw uses the 1st hole in from the front of the runner. Finished front edge The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 19 Assembly Instructions Step 27 Fit the small divider Push the small divider onto the base Use a screwdriver to tighten the 2 large locking nuts fitted to the small divider Step 28 Fit the 2 rails and the 2nd back rail Push the 2 rails onto the right side...
- Page 20 Assembly Instructions Step 29 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 6 large locking nuts shown, fitted to the top , the base , the 2 rails and the back rail Step 30 Fit the mushroom head pins...
- Page 21 Assembly Instructions Step 31 The measurement from top corner X to bottom corner X must be Fit the back panels equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x:x equals Note: Do not y:y.
- Page 22 Assembly Instructions Step 33 Fit the 2 hanging rails Push the hanging rails into the rail holders fitted to the side panels and large divider. Step 34 Fit the 2 drawers Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panels and push...
- Page 23 Assembly Instructions Step 35 Prepare the right hand door Important: Check that the holes are in the same place as the diagram. Push 2 top glides into 1 of the doors This will be the Push 2 bottom glides right hand door into the same door and secure each one with 2 screws...
- Page 24 Assembly Instructions Step 37 IMPORTANT Drill 2 handle holes in Carefully choose which 2 holes each of the doors you need to drill in each door Important: Please follow these instructions carefully. Lay the 2 doors down onto a smooth ONLY drill these 2 holes surface.
- Page 25 Assembly Instructions Step 38 Fit the doors With the top of the right hand door leaning back at an angle, insert the bottom glides into the rear track Push the top of the right Right hand door in and hand door locate the top glides Buffer bracket into the rear track...
- Page 26 Assembly Instructions Step 39 IF YOUR DOORS DO NOT RUN SMOOTHLY Adjust the doors if needed If your doors are not running smoothly, please follow these instructions to adjust the bottom glides. Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown.
- Page 27 Assembly Instructions Step 40 Attach the handles Attach a handle each of the doors using 2 screws...
- Page 28 Lift with care. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2998...
