Linear - 5 Drawer Chest
Assembly Instructions -
Dimensions
Width - 79.5cm
Depth - 39cm
Height - 104cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
247/6216
278/1671
266/8732
MADE IN
BRITAIN
Issue 1 - 10/06/14
Advertisement
Related Manuals for Argos Linear 247/6216
Summary of Contents for Argos Linear 247/6216
- Page 1 Linear - 5 Drawer Chest Assembly Instructions - 247/6216 Please keep for future reference 278/1671 266/8732 Dimensions Width - 79.5cm Depth - 39cm MADE IN Height - 104cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 10/06/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 35.5kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (DF143) (795 x 390mm) Left Side Right Side Cross Rail (DF843) (DF844) (DF144)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 5 drawer fronts Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 7 Fit the wedgefixes Turn the drawer assemblies over and slide 4 wedgefixes into the front and back grooves, as shown, and tighten up the screws. Step 8 Runners must be Fit runners to the pushed up against drawers the drawer front Fit the runner...
- Page 8 Assembly Instructions Step 9 screw screw screw Prepare the left side Fit 5 runners the left side The 1st screw uses the 2nd hole in from the Finished front of the runner. front edge The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 9 Assembly Instructions Step 10 screw screw screw Prepare the right side Fit 5 runners the right side The 1st screw uses the 2nd hole in from the front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 10 Assembly Instructions Step 11 Prepare the cross rail Tap 2 wooden dowels into the cross rail Insert 2 large locking Finished nuts into the front edge cross rail Step 12 Fit the cross rail to the right side Push the cross rail onto the right side Use a screwdriver to tighten the large locking...
- Page 11 Assembly Instructions Step 14 Prepare the top Screw 4 metal dowels into the top Fix the bracket in the middle of the top flush to the rebated back edge using screw Finished front edge Step 15 Fit the top Push the top onto the assembly.
- Page 12 Assembly Instructions Step 16 Fit the base Fit the base onto the assembly using 4 screws Finished front edge Step 17 Fit the feet Fit the feet to the base using screws...
- Page 13 Assembly Instructions Step 18 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 14 Assembly is complete Side panel Drawer If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 16 ALR3058...
