Checklist for Total Measurements
Please view the real-time measurements in the Bubble-screen of the App or the
Dashboard. Run the following checks:
Check Description
1. The total consumption-bubble (grey) should display plausible values.
Compare the results with the main utility meter.
2. The total production bubble (green) should display plausible values.
Compare the results with the solar inverter or batteries.
3. When appliances turn on or off, the consumption-bubble should
change accordingly.
4. When appliances in the sub-meter circuits turn on or off, the
consumption-bubble should change accordingly. (Make sure it does
not display the double power value).
5. When appliances in the sub-meter circuits turn on or off, the correct
name should be displayed in the App.
6. Perform the checks above for appliances on all three phases.
Troubleshooting
If the checks above show unexpected results, please verify the following installation
steps:
Check Description
1. The wiring of the green 8-pin connector.
2. The installation of the Current Transformers.
3. The correct configuration in the "Configuration" menu.
4. The correct configuration in the "Channel Configuration"
menu.
Once all checks are successfully completed, you may finish up the installation work.
Please see the next page for the final steps.
Smappee Plus Installation Manual
Version 1.6.2 B, 20-06-2017, rev 4
See
page 8
page 11
page 27
page 23
Page 30 of 32
