Overview over the Installation Steps

Step-by-Step
The table below provides a global overview over all steps for installing the Smappee.
Please follow these steps carefully and in the provided sequence.
Step Title
Hardware and Physical Installation
1 Error! Not a valid bookmark self-reference.
2 Overview over the Installation Steps
3 The connectors and Inputs of the Smappee
4 Connecting the Power Supply
5 Connecting the Voltage Measurement Wires
6 Connecting the Current Transformers (CTs)
7 Current Transformer Variants
8 Preparing the Internet Connection
First Power-On
9 Initial Power-On of the Smappee Monitor
Connecting and Configuring
10 Login to the Smappee App
11 Connect to Internet and Cloud
12 Troubleshooting Internet and Cloud Access
13 Configure the Current Transformers
14 Where to Modify the CT configuration
15 Configuration Settings for
16 Configure the Smappee in the Expert Portal
17 Diagnose the Smappee in the Expert Portal
19 Checklist for Correct Configuration
Wrapping-Up
20 Mounting and Enclosing
21 Final Remarks
Smappee Plus Installation Manual
Version 1.6.2 B, 20-06-2017, rev 4
Page
3
3
5
7
8
11
12
13
14
15
16
18
20
21
23
25
27
29
31
32
Page 3 of 32
