Initial Power-On of the Smappee Monitor

Introduction
Your Smappee Plus monitor is now nearly ready for the first power-on. Please
complete a number of checks, before you power-on the Smappee.
Important: The Smappee Plus is not yet completely installed and insulated.
Perform the actions of section "Mounting and Enclosing", on page 31, before
leaving the installation place.
Check Before First Power-On
Please do a final check:
ID Check
1. Smappee is connected by a circuit breaker.
2. The 8-pin connector block is correctly wired for both the main
power supply as well as the measuring wires.
3. The current transformers are connected at your electrical
installation and to the inputs at the Smappee.
4. The hardware for the network (Ethernet cable or USB dongle)
is connected to the Smappee.
5. You understand that the Smappee Plus is not yet completely
installed and properly insulated.
installation before completing the installation.
Power On
Now use the circuit breaker to turn on the power.
Lights for Network Status
Smappee indicates the progress of the power-on and the network status by the light.
Light Description
Blue Steady The Smappee is powering on. Please wait for about 3 minutes.
Hint: The light may briefly go dark during that time.
Green Steady The Smappee is connected to the local network and ready to be
installed by the App. The Smappee should show this color when
it is connected by Ethernet or a 3G/4G dongle.
Blue Flashing The Smappee monitor is ready to be connected to the local
network and to be installed by the App. The Smappee should
show this color when it is connected by a Wi-Fi dongle.
If you see one of these colors, proceed to the next page of this manual.
If, however, Smappee shows a different color, please refer to section "Troubleshooting
Internet and Cloud Access" on page 18.
Smappee Plus Installation Manual
Version 1.6.2 B, 20-06-2017, rev 4
Do not leave the place of
More info
page 7
page 8
page 11
page 13
page 31
Page 14 of 32
