Box Contents
Key Description
1 Front Plate
2 Back Plate
3 Lever Handles
4 Gasket x 2
5 Sprung Spindle
6 Fire Cup
7 1.5v AA Batteries (x4)
8 Mortice Latch, Strike and 4 Screws
9 Fixing Bolts x 4 (Inc spare)
10 Cable Tube and Ring Nut and Cap
11 Alignment Insert
12 Latch Support Post
13 Allen Keys
14 Cable Connections for REM1 and REM2
15 Front Plate Cylinder Keys
16 Front Plate Cylinder Cover
17 Classroom Function Tailpiece
18 Data Transfer Cable (optional)
19 USB Connector (optional)
20 USB Stick (optional)
21 PCB for Audit Trail (optional)
This box should also contain an Installation Template
and Programming and Operating Instructions.
Tools Required
• Philips screwdriver • Hammer/mallet
• Pliers (for cutting bolts) • Stanley knife
• Power drill
• Chisel 25mm (1")
• Drill bits -
• Adhesive tape, pencil,
bradawl, tape measure
2
Please check the contents
of the box are correct
6
10mm ( 3 /8"), 25mm (1")
and 54mm (2 1 /8")
3
/
70mm (2 ")
4
