Environmental specifications

• Minimum/maximum ambient operating temperatures: 0 to 40º C
• Minimum/maximum storage temperature: –40 to 75º C
• Maximum altitude for operation: 3,000 meters
• Maximum altitude for transport: 12,000 meters
• Operating humidity: 20 to 80% relative humidity (non-condensing)
• Storage humidity: 5 to 95% relative humidity (non-condensing)

Matrox MXO2 Mini specifications

General

• Video formats
• Regulatory compliance
FCC Class A, CE Mark Class A, ACMA C-Tick Mark, VCCI
$
RoHS Directive 2002/95/EC
$
• Dimensions
Length 166 mm (6.5")
$
Width
$
Height
$
• Operating voltages and power consumption
Included AC/DC adapter: 100-240 V AC 50-60 Hz (5 V DC, 3 A max)
$
MXO2 Mini unit: 5-25 V DC, 2.5 mm barrel-type connector
$
•
9 watts power consumption

Connections

Video
• HDMI video
HD input and output
$
•
HDMI Y,Cb,Cr 4:2:2 (10-bit) / RGB (10-bit)
•
Eight channels of embedded audio
•
Standard Type A HDMI connector (19 pins)
SD output
$
•
HDMI Y,Cb,Cr 4:2:2 (10-bit) / RGB (10-bit)
•
Eight channels of embedded audio
•
Standard Type A HDMI connector (19 pins)
NTSC, PAL, NTSC-EIAJ, 1080i/p/PsF, 720p, 576p, 480p
110 mm (4.3")
40 mm (1.6")
Matrox MXO2 Mini specifications
