Frame Features //
• Adjustable Travel: 4.5" to 5" (115mm OR 130mm)
• 27.5+" Wheel size
• 5.3 lbs / 2,420 grams = Standard frame w/ alloy link, no shock, size m
• Tapered Head Tube
• Monocoque front triangle
• Integrated BOOST 148 x 12 dropouts
• Internal Brake and Derailleur Cable Routing System
• Internal Seat Tube Cable Routing for dropper posts
• Angular Contact/Collet Bearing System with replaceable Grease Zerks
• Flack guard Downtube and Chainstay protection
• H20 Bottle Fitment
Component Spec //
• Fork – 1.5" tapered steer, 150mm Travel, 561mm lower leg length, 51mm offset
• Shock – 200mm x 50.8mm (7.875" x 2"), 22mm x 6mm and 30mm x 6mm reducers
• 1x gearing only
• Seat post – 31.6mm
• Headset – zero stack 44 upper / external cup 49 lower
• Bottom bracket - Press Fit BB92
• Rear Axle – BOOST 148 x 12 T/A
• Brake Mount – post mount for 160mm rotor
• Crank set - BOOST 148 Compatible - single ring only
• Rear Wheel - BOOST 148 Compatible
