- Page 2 WELCOME TO THE REGISTER YOUR BIKE AT: www.intensecycles.com/pages/registerbike INTENSE FAMILY! CONGRATULATIONS ON YOUR NEW INTENSE 951 XC BIKE! AT INTENSE WE HAVE FOR TECHNICAL ASSISTANCE: ONE GOAL - Email info@intensecycles.com Phone +1 951-307-9211 TO PROVIDE THE RIDE OF YOUR LIFE! CONTENTS 04-05 Getting to know your bike...
- Page 3 GRIPS HANDLEBARS INTENSE 951 XC STEM GETTING TO KNOW YOUR BIKE DROPPER POST LEVER SHIFTER Featuring a super lightweight full carbon frame, rolling on 29” wheels, with progressive and modern XC geometry, and 120mm of suspension travel, the SADDLE INTENSE 951 XC is our state-of-the-art full suspension (SEAT) TOPTUBE cross country mountain bike.
- Page 4 WHAT ELSE IS IN THE BOX? GETTING TO KNOW YOUR TOOLS The first thing to do is familiarize yourself with the contents of the toolbox, included in your bike box. If you are confident with tools then great, if you are not, take your time looking through everything and getting to know how each item works.
- Page 5 N E E D H E L P ? DO NOT RETURN TO THE STORE call us at: +1 951.307.9211 or email: info@intensecycles.com our rider support team looks forward to helping with any questions. INTENSE 951 XC SETUP GUIDE Your new 951 XC is almost ready to go, you just need to do a few things to get your bike ready for the ride.
- Page 6 STEP 01 REMOVE WHEELS AND PREPARE BIKE The packaging sections are individually Remove the toolbox and accessories When tightening the bolts follow this Replace the faceplate of the stem and reinsert the bolts, firstly by hand and pattern to ensure even clamping: top numbered to make it easy for you to and place nearby.
- Page 7 STEP 04 STEP 05 INSTALL DERAILLEUR INSTALL THE REAR WHEEL POSITION AT 70° DERAILLEUR B SCREW TO THE AXLE Remove the orange plastic brake pad There is a integrated metal lever that sits Move to the rear of the bike and cut off At this point be careful that the notch inside the axle.
- Page 8 STEP 07 RUN THROUGH THE GEARS Now is a good time to run through the gears to INSERT check that they are working correctly. To do this AXLE FROM turn the cranks (where the pedals are attached) NON-DRIVE so that the wheel begins to spin, with your hand SIDE PUSH TOWARD THE FRONT OF...
- Page 9 STEP 09 ADJUST SADDLE HEIGHT Set the height of your saddle (seat) with your seatpost in its fully extended position. Using a 4mm Allen key loosen the seatpost clamp and adjust the seatpost to the correct height. A good base measurement is to stand next to your bike in riding shoes, putting your hand against the top of your hip bone the palm of your hand should be level with the top of the saddle.
- Page 10 The recommended settings below are designed to be a starting point, in order to get you out STEP 12 on your first ride in as few steps as possible. As you ride and get used to your new fork, adjust your settings as explained in step 13.
- Page 11 STEP 13 FOX PERFORMANCE FLOAT DPS. REAR SUSPENSION SETUP 3-POSITION (OPEN, TRAIL, LOCK-OUT) SUGGESTED STARTING POINTS COMPRESSION LEVER FOR SETTING UP YOUR SHOCK RIDER WEIGHT AIR PRESSURE REBOUND (lbs/kgs) (psi) (clicks out from fully closed) Closed is Clockwise COMPRESSION Open is Counterclockwise 100lbs / 45kgs ADJUSTMENTS 110lbs / 50kgs...
- Page 12 These drawings, any and all specifications and data herein contained and the products manufactured in accordance with the said drawings, specifications and data are the exclusive property of Intense Cycles of Temecula, CA (USA), in accordance with the provisions of the National laws and International Conventions UNTOLERANCED LENGTH DIMENSIONS (mm) for the protection of Intellectual Property.
- Page 13 FRAME SPECS COMPONENT LIST Model: INTENSE 951 SERIES XC Model: INTENSE 951 SERIES XC Model Year: 2021 Model Year: 2021 Frame sizes available: Small (S), Medium (M), Large (L) and Extra Large (XL) Compatible Forks: 120mm Travel Headtube/Headset: Integrated IS41-IS52/40...
- Page 14 LOOKING AFTER YOUR BIKE MAINTENANCE SCHEDULE MAINTENANCE Action Every Ride 500 Miles 2000 Miles 4000 Miles or 1 Month or 6 Months 1 Year You have purchased a high-performance bicycle which requires a certain level of service and TIRES Check air pressure, inspect tread and maintenance to sustain the level of performance your frame was designed around.
- Page 15 INTENSE 951 XC ITEM PART No. DESCRIPTION QTY. TORQUE SPEC. PARTS LISTINGS Bearing Cap 24mm OD 130765 Cap Bearing Blk Bolt Main Pivot 130791 Bolt Main Pivot 1.5t Expander Blk 7Nm / 60in-lbs Cone Adjuster 130807 Spacer Cone Adjuster Blk, 8.3mm Height Injection Top Link 130823 Link Top 951 XC Injection Blk...
- Page 16 INTENSE 951 XC PARTS KITS AXLE KIT IT130846 Axle Kit Rear CNC 148 x 12 Boost With Hidden Lever 951 Series XC HARDWARE KIT UPPER IT150129 Link Kit Upper Hardware Stainless 951 Series XC IT130846 Axle Rear 148 x 12mm Boost Blk with Hidden Lever...
- Page 17 N E E D H E L P ? DO NOT RETURN TO THE STORE call us at: +1 951.307.9211 or email: info@intensecycles.com our rider support team looks forward to helping with any questions.
