2.2

Monitoring select Switch

3.0

Pin-out Details

3.1

Analogue XLR Connectors

ANALOG 1
ANALOG 1
ANALOG 1
ANALOG 2
ANALOG 2
ANALOG 2
3.2

AES XLR Connectors

AES1
AES 1
AES 1
AES 2
AES 2
AES 2
AMU1-CHD+mk2
This switch allow stereo, Left, Right and Mono to be monitored
from the internal loudspeakers and line outputs.
N.B. Position D is spare.
C
PIN
1
2
3
1
2
3
C
PIN
1
2
3
1
2
3
FUNCTION
GND
1 IN+
1 IN-
GND
2 IN+
2 IN-
FUNCTION
GND
1 IN+
1 IN-
GND
2 IN+
2 IN-
Issue 1
