- Page 1 AMU2-2MA AUDIO MONITORING UNIT HANDBOOK Television Systems Limited. Vanwall Road, Maidenhead, Berkshire, SL6 4UB Telephone +44 (0)1628 676200, FAX +44 (0)1628 676299 AMU2-2MA MKIII ISSUE 1...
- Page 2 AMU2-2MA MKIII ISSUE 1...
- Page 3 Type of Equipment: Audio Video Monitoring Unit Model No: AMU2-2MA MKIII Part Number: TSLP- AMU2-2MA MKIII Date CE Mark Affixed: 15/11/99 I, the undersigned, declare that the equipment specified above conforms to the quoted Directives and Standards. Place: Maidenhead, England...
- Page 4 AMU2-2MA MKIII ISSUE 1...
- Page 5 WARRANTY, MAINTENANCE AND REPAIR All TSL equipment is guaranteed for one year from the date of delivery to the customer’s premises. If the equipment is to be stored for a significant period, please contact TSL concerning a possible extended warranty period.
- Page 6 AMU2-2MA MKIII ISSUE 1...
- Page 7 ? Symptoms of the fault (to include switch setting positions, input signals etc): Packing Please ensure that the unit is well packed as all mechanical damage is chargeable. TSL recommends that you insure your equipment for transit damage. The original packaging, when available, should always be used when returning equipment..
-
Page 8: Table Of Contents
Audio Output Connector - D25 Plug Control Connector - D9 Socket External Connector - D15 Plug LS Output AMU Alignment Procedure Initial Set-Up Audio Alignment AMP-2 PPM Calibration Procedure VU Calibration Procedure Bargraph Calibration Procedure General Notes AMU2-2MA MKIII ISSUE 1... - Page 9 AMU2-2MA MKIII ISSUE 1...
-
Page 10: Introduction
AMU2-2MA MKIII AUDIO MONITORING UNIT Introduction The AMU2-2MA MKIII is a 2RU x 300mm deep Audio Monitoring Unit with Sifam PPM or VU meters. The following features are standard: ? Two Sifam 32 style meters. ? Eight switch selectable stereo analogue inputs. -
Page 11: Output Switching
Remote Mute of either or both of the LS O/Ps and Variable Line O/Ps are possible via a rear connector. A ground is required on the appropriate pin to activate the MUTE condition. VOLUME The Headphones O/P and the Variable Line O/P may be varied. AMU2-2MA MKIII ISSUE 1... -
Page 12: Amp-2 Facilities
AMP-2 Facilities This card provides all of the analogue processing. AMU2-2MA MKIII ISSUE 1... -
Page 13: Pin-Out Details
ANALOGUE 2 2 IN+ ANALOGUE 2 2 IN- ANALOGUE 3 ANALOGUE 3 3 IN+ ANALOGUE 3 3 IN- ANALOGUE 4 ANALOGUE 4 4 IN+ ANALOGUE 4 4 IN- ANALOGUE OUT ANALOGUE OUT OUT+ ANALOGUE OUT OUT- AMU2-2MA MKIII ISSUE 1... -
Page 14: Audio Input Connector - D50 Socket Pinouts
I/P6 A1 SCREEN I/P6 A2 SCREEN I/P7 A1 SCREEN I/P7 A2 SCREEN I/P7 A1 I/P7 A2 I/P7 A1 I/P7 A2 I/P8 A1 I/P8 A2 I/P8 A1 I/P8 A2 I/P8 A1 SCREEN I/P8 A2 SCREEN SCREEN SCREEN AMU2-2MA MKIII ISSUE 1... -
Page 15: Audio Input Connector - D50 Socket
Audio Input Connector - D50 Socket AMU2-2MA MKIII ISSUE 1... -
Page 16: Audio Output Connector - D25 Plug
SCREEN A2- FIXED A3+ FIXED SCREEN A3- FIXED A4+ FIXED SCREEN A4- FIXED A1+ VARIABLE SCREEN A1- VARIABLE A2+ VARIABLE SCREEN A2- VARIABLE 23,12,13 SCREEN Control Connector - D9 Socket This is wired for RS422. CONTROL AMU2-2MA MKIII ISSUE 1... -
Page 17: External Connector - D15 Plug
All model variants are covered here so the user will understand the function of the various controls. It is recommended that an exchange card is obtained from TSL in the event of a fault. Due to the complexity of these circuit cards TSL use a custom jig for accurate alignment. -
Page 18: Initial Set-Up
PCB for -4 VU. (0VU = +4dBu). Bargraph Calibration Procedure The drives for the RTW bargraph meters are taken from the AMP-2 card pins C24 and C25, left and right respectively AMU2-2MA MKIII ISSUE 1... -
Page 19: General Notes
General Notes Please note that some American equipment has the function of the XLR pins 2 & 3 reversed. TSL product is wired to the European standard AMU2-2MA MKIII ISSUE 1... - Page 20 AMU2-2MA Mk3 Technical Specifications Power Supply Supply Voltage 90 -250V AC @ 50Hz/60Hz +/- 10% Power Consumption 150 VA Max. Physical Dimensions Height 88mm (2RU) Width 483mm (19”) Depth 300mm Weight 4800gm Inputs 1, 2, 3 & 4. Connector Type XLR Female 3 pin.
- Page 21 AMU2-2MA MKIII ISSUE 1...
