TSL AMU2-8HD+ Handbook

Audio monitoring unit
Hide thumbs

Advertisement

Table of Contents

AMU2-8HD+ & 3G
Audio Monitoring
Units
Handbook
TSL
Vanwall Road, Maidenhead, Berkshire, SL6 4UB
Telephone +44 (0)1628 676200, FAX +44 (0)1628 676299

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMU2-8HD+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TSL AMU2-8HD+

Summary of Contents for TSL AMU2-8HD+

  • Page 1 AMU2-8HD+ & 3G Audio Monitoring Units Handbook Vanwall Road, Maidenhead, Berkshire, SL6 4UB Telephone +44 (0)1628 676200, FAX +44 (0)1628 676299...
  • Page 2 AMU2-8HD+/3G Issue 1...
  • Page 3 Do not switch on until all connections are made. WARRANTY, MAINTENANCE AND REPAIR All TSL equipment is guaranteed for one year from the date of delivery to the customer’s premises. If the equipment is to be stored for a significant period, please contact TSL concerning a possible extended warranty period.
  • Page 4 • Symptoms of the fault (to include switch setting positions, input signals etc): Packing Please ensure that the unit is well packed as all mechanical damage is chargeable. TSL recommends that you insure your equipment for transit damage. The original packaging, when available, should always be used when returning equipment..

  • Page 5: Table Of Contents

    Contents Introduction Front Panel Controls Input and Meter Selection Buttons Output Switching and monitoring Pin-out Details Line output Analogue Output Connector – D25 Socket Pinout AES Input/Output connector – D25 Socket Pinout Control Connector - D9 Socket External Connector - D15 Plug S/HD BNC connectors Re clocked BNC connector Down converted BNC connector...

  • Page 6: Introduction

    Introduction This handbook covers the AMU2-8HD+ and AMU2-8HD-3G Audio Monitoring Units. The AMU2-8HD+/3G are full rack 2RU x 310mm deep Audio Monitoring Units with eight TSL 53 segment bargraphs. The following features are standard: • Four AES/EBU inputs. • Two HD/SDV auto sensing inputs.

  • Page 7: Front Panel Controls

    Front Panel Controls Input and Meter Selection Buttons AES1, 2, 3 & 4 AES input. This is selected by first pressing the AES select button, then selecting A(1/2),B(3/4), C(5/6), D(7/8) respectively on the LS monitoring panel. Analogue 1 & 2 These inputs selected...

  • Page 8: Output Switching And Monitoring

    Meta Data Display This window indicates: Channel coding (Rate/non PCM/Dolby D/Dolby) Channel format (e.g. 8x1/2+2+2+2 etc) Digital peak read out of selected pair. Dialogue normalisation value where set N.B. To reset/refresh display press Phase Reverse then Dolby select switches simultaneously. Output Switching and monitoring A, B, C &...

  • Page 9: Pin-Out Details

    Pin-out Details Line output XLRS FUNCTION ANALOG 1 ANALOG 1 1 IN+ ANALOG 1 1 IN- ANALOG 2 ANALOG 2 2 IN+ ANALOG 2 2 IN- D25 Socket, Analogue output connector D 25 SOCKET AUDIO OUTPUTS ON AMU PIN NO FUNCTION A8+ (7.1) A8- (7.1)

  • Page 10: Control Connector - D9 Socket

    3.3 D25 Socket, AES Input/Output connector D 25 SOCKET AES INPUTS/OUTPUTS ON AMU PIN NO FUNCTION Ch1&2 Input 1+ Ch1&2 Input 1- Ch3&4 Input 2+ Ch3&4 Input 2- Ch5&6 Input 3+ Ch5&6 Input 3- Ch7&8 Input 4+ Ch7&8 Input 4- Ch1&2 Output 1+ Ch1&2 Output 1- Ch3&4 Output 2+...
  • Page 11 External Connector – D15 Plug EXTERNAL FUNCTION Lt Rt enable S/HD connectors This input auto detects HD or SDV signals. Re clocked connector This connector gives a re clocked output of the selected H/SDI input signal. Video output connector This gives a down converted output of HD (Vision only) or a composite PAL/NTSC video.

  • Page 12: Remote Control Connector/ Rs 422 - D9 Socket

    Remote Control Connector/ RS 422 - D9 Socket This is wired for RS422. CONTROL 3.10 Aux (Dolby Metadata) - D9 Socket This is wired for RS422. CONTROL LS Output This is a single ended amplifier therefore one side may be connected to ground. AMU2-8HD+/3G Issue 1...

  • Page 13: Configuration Switch Functions

    Configuration Switch Functions (z12a.hex/z13.mcs FPGA) ACI code 7.03 (Note:Subject to change) SWITCH FUNCTION SECTION Loudspeaker O/P mute - UP D25 Anlg variable – Up/Fixed - Dwn AES variable –Up/Fixed -Dwn XLR line O/P’s fixed – Up/variable-Dwn Lo Ro-Up/Lt Rt-Dwn Comp out-Up/ SDI - Dwn ** This output on the first pair of the D25 –...
  • Page 14 Please note that some American equipment has the function of the XLR pins 2 & 3 reversed. TSL product is wired to the European standard The Dolby (CAT552) card can be reset by pressing the phase reverse and the Dolby select buttons simultaneously.

  • Page 15: Specification

    AMU2-8HD+/3G Technical Specifications Power Supply Supply Voltage 100 -240V AC @ 50Hz/60Hz +/- 10% Power Consumption 60 Watts. Supply Voltage 12V DC Physical Dimensions Height 88mm (2RU) Width 483mm (19”) Depth 280mm Weight 3500gm Input 1 and 2 Connector Type XLR 3 pin.
  • Page 16 Setup Flash card port. (Factory use only) Dolby Dolby Digital or Dolby E decoding from selected AES input or selected embedded audio. Note: The Dolby (CAT522) card can be reset by pressing the phase reverse and the Dolby select buttons simultaneously. Display indicates: Channel coding (rate/non pcm/dolby D/dolby)

  • Page 17: Block Schematic Diagram

    HD Standards Supported 1080p/50/59.94/60Hz (3G units only) 1080i/50 1080i/59.94 1080i/60 720p/50 720p/59.94 720p/60 8.0 Block schematic Diagram AMU2-8HD+/3G Issue 1...
  • Page 18 AMU2-8HD+/3G Issue 1...
  • Page 19 AMU2-8HD+/3G Issue 1...
  • Page 20 Front and rear Panel layouts AMU2-8HD+/3G Issue 1...
  • Page 21 AMU2-8HD+/3G Issue 1...

This manual is also suitable for:

Amu2-8hd-3g
