AMU2-BHD+
Audio monitoring
Unit
Handbook
TSL Products
Units 1-2, First Avenue, Globe Park, Marlow, Bucks, SL7 1YA
Telephone +44 (0)1628 564610

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMU2-BHD+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TSL AMU2-BHD+

Summary of Contents for TSL AMU2-BHD+

  • Page 1 AMU2-BHD+ Audio monitoring Unit Handbook TSL Products Units 1-2, First Avenue, Globe Park, Marlow, Bucks, SL7 1YA Telephone +44 (0)1628 564610...
  • Page 2 AMU2-BHD+-6 ISSUE 6...
  • Page 3 Do not switch on until all connections are made. WARRANTY, MAINTENANCE AND REPAIR All TSL equipment is guaranteed for one year from the date of delivery to the customer’s premises. If the equipment is to be stored for a significant period, please contact TSL concerning a possible extended warranty period.
  • Page 4 • Symptoms of the fault (to include switch setting positions, input signals etc): Packing Please ensure that the unit is well packed as all mechanical damage is chargeable. TSL recommends that you insure your equipment for transit damage. The original packaging, when available, should always be used when returning equipment..

  • Page 5: Table Of Contents

    Contents Introduction Front Panel Controls Input and Meter Selection Buttons Output Switching Pin-out Details Analogue XLR Connectors AES/EBU XLR Connectors Analogue Output Connector – D25 Socket Pinout AES Input/Output Connector – D25 Socket Pinout Control Connector - D9 Socket External Connector - D15 Plug Configuration Switch Functions LS Output General Notes...

  • Page 6: Introduction

    • Two HD/SDV auto sensing input with Group select. • Four AES/EBU inputs. • Two switch selectable stereo analogue inputs. • One TSL bargraph. • Phase reverse switch. • Phase correlation bargraph. • Re clocked output of either HD or SDV •...
  • Page 7 2.1.1 TSL Bargraph Set-up Menus. These are accessed via the select & change buttons located between the two alphanumeric displays to the left of the unit (see diagram above). The top display shows the function & the bottom gives the state.
  • Page 8 Pressing select a second time gives: All the LEDs are lit up to the highest level displayed. Pressing the change button gives: Only the highest level LED is lit. Pressing select a third time gives: Pressing the change button gives: .1ms This changes the response for the relevant scales.
  • Page 9 Pressing select for a fifth time gives: Depressing the change button changes the brightness or intensity of the display. Successive presses decrease brightness. Pressing select for a sixth time gives: Depressing the change button changes the input from Analogue to digital (AES). Pressing select for a seventh time gives: Depressing the change button defines which scale is in use.

  • Page 10: Front Panel Controls

    Front Panel Controls Input and Meter Selection Buttons S/HD 1&2 Pair 1, 2 Selects A1/A2 or A3/A4 from the de-embedded HD or SD to the meters. Group Select Toggles to decode the required group within the embedded audio signal. AES1, 2, 3 & 4 Selects one of four AES signals to the meters.

  • Page 11: Output Switching

    Output Switching A1/A2 These buttons select either: - The Analogue Left or Right signals of the metered Input, - The AES/EBU Input 1 Left or Right signals or - The selected SDV group A1 & A2 decoded outputs to the Left or Right Output Channels. The buttons toggle.

  • Page 12: Pin-Out Details

    Pin-out Details Analogue XLR Connectors XLRS FUNCTION ANALOGUE 1 ANALOGUE 1 1 IN+ ANALOGUE 1 1 IN- ANALOGUE 2 ANALOGUE 2 2 IN+ ANALOGUE 2 2 IN- AES/EBU XLR Connectors XLRS AES FUNCTION AES 1 AES GND AES 1 AES 1 IN+ AES 1 AES 1 IN- AES 2...

  • Page 13: Analogue Output Connector – D25 Socket Pinout

    Analogue Output Connector – D25 Socket Pinout D 25 SOCKET AUDIO OUTPUTS ON AMU PIN NO FUNCTION Ground Ground AMU2-BHD+-6 ISSUE 6...

  • Page 14: Aes Input/Output Connector – D25 Socket Pinout

    AES Input/Output Connector – D25 Socket Pinout D 25 SOCKET AES INPUTS/OUTPUTS ON AMU PIN NO FUNCTION Ch1&2 Input 1+ Ch1&2 Input 1- Ch3&4 Input 2+ Ch3&4 Input 2- Ch5&6 Input 3+ Ch5&6 Input 3- Ch7&8 Input 4+ Ch7&8 Input 4- Ch1&2 Output 1+ Ch1&2 Output 1- Ch3&4 Output 2+...

  • Page 15: Control Connector - D9 Socket

    Control Connector - D9 Socket This is wired for RS422. CONTROL External Connector – D15 Plug. EXTERNAL FUNCTION GPI 1 GPI 2 GPI 1 &2 - Remote Dim and Cut. AMU2-BHD+-6 ISSUE 6...

  • Page 16: Configuration Switch Functions

    Configuration Switch Functions (from S/W Release X06) SWITCH SECTION FUNCTION Not Used Not Used Speaker Mute Up Digital Settings (see table below) Digital Settings (see table below) Digital Settings (see table below) Not Used Composite out-Up/SDI /Down FUNCTION -24dBFS -22dBFS -20dBFS -18dBFS -15dBFS...
  • Page 17 Please note that some American equipment has the function of the XLR pins 2 & 3 reversed. TSL product is wired to the European standard AMU2-BHD+-6 ISSUE 6...

  • Page 18: Specification

    AMU2-BHD+ Technical Specifications Power Supply Supply Voltage 100 -240V AC @ 50Hz/60Hz or 12V DC Power Consumption 35W. Fuse Rating Physical Dimensions Height 88mm (2RU) Width 483mm Depth 310mm Weight 3.5Kg Analogue Input 1 & 2 Connector Type XLR 3 pin. Pin 1 Gnd, Pin 2 hot, and Pin 3 cold. Signal Balanced line level audio.
  • Page 19 Outputs AES 1, 2, 3 & 4 AES I/O, 25 way D type See section 3.4 for details Noise Better than -60dB (22Hz to 22 KHz) Headphone Output. Connector Stereo Jack socket type A Impedance 50Ω Output Levels Through level control with 0dB gain. Loudspeaker Outputs.

  • Page 20: Front And Rear View

    Front and rear view AMU2-BHD+-6 ISSUE 6...

  • Page 21: Block Schematic

    Block Schematic AMU2-BHD+-6 ISSUE 6...
