3.4 AES Input/Output Connector – D25 Socket Pinout, Plug (shown) on mating cable.
D 25 SOCKET AES INPUTS/OUTPUTS
ON AMU
PIN NO
1
14
2
15
3
16
4
17
5
18
6
19
7
20
8
21
9
22
10
23
11
24
12
25
13
To use an unbalanced input pin 17 must be grounded. D-25 pins 10, 12,
17, 13, 22, 23, 24 and 25 are available for this purpose.
AMU1-CHD+mk2
FUNCTION
Ch1&2 Input 1+
Ch1&2 Input 1-
Ch3&4 Input 2+
Ch3&4 Input 2-
Ch5&6 Input 3+
Ch5&6 Input 3-
Ch7&8 Input 4+
Ch7&8 Input 4-
Ch1&2 Output 1+
Ch1&2 Output 1-
Ch3&4 Output 2+
Ch3&4 Output 2-
N/C
N/C
N/C
N/C
N/C
Ground
Ground
Ground
N/C
Ground
Ground
Ground
Ground
Issue 1
