1.0

Introduction

The AMU1-CHD+ mk2 is a 1RU x 320mm deep Audio Monitoring Unit with two 26 segment
bargraphs for audio level measurement.
The following features are standard:
• Two switch selectable stereo analogue inputs
• Four AES /EBU inputs
• Two HD/SDV auto sensing inputs
• Out-of-phase error indication
• EBU Digital and PPM metering scales
• Encoded PAL/NTSC composite or SDI output (Switch selectable)
• Re-clocked serial output of the selected input
• Integral loudspeaker system
• 40 Watt total amplifier power with 12VDC input
• Headphone outputs with LS muting
• Two 12V DC inputs
• Stereo /multi channel line outputs
• Two decoded AES outputs
• Variable line output
2.0

Front Panel Controls and Indicators

2.1

Input and Meter Selection Switches

Digital Source Select
Channel Select
Meters
Phase
Volume Control
AMU1-CHD+mk2
Selects AES 1-2 and 3-4 (in conjunction with the channel
switch) and SDI 1 & 2 Groups 1-4
Selects AES1,2,3 and 4 and pairs 1 (D1) and 2 (D2) from both the
SDV inputs. Analogue 1 and 2 are also selected in position Anl 1
and Anl 2.
Left Channel is fed to the left bargraph and Right Channel is fed to
the right bargraph.
Momentary phase reverse between A1 and A2 pairs. A non
latching push switch with Red/Green LED indicates phase. Push to
reverse.
Allows the audio level to be varied.
