  • Page 2 P a g e SAFETY Installation. Unless otherwise stated TSL equipment may be installed at any angle or position within an All TSL equipment conforms to the EC Low Voltage Directive: EC Low Voltage Directive (73/23/EEC)(OJ L76 26.3.73)(LVD). Amendment: (93/68/EEC) (OJ L220 30.8.93).
  • Page 3  Symptoms of the fault (to include switch setting positions, input signals etc): Packing Please ensure that the unit is well packed as all mechanical damage is chargeable. TSL recommends that you insure your equipment for transit damage. The original packaging, when available, should always be used when returning equipment.
  • Page 4 P a g e This Page is Blank AVM-T-MIX User Handbook Version Three...

  • Page 5: Table Of Contents

    P a g e Table of Contents Introduction ..........................7 Block Diagram ........................9 Operation ..........................10 Controls and Displays - Overview ..................11 Source Selection ........................14 Analogue Audio Input Trim ....................15 Channel Signal Format Selection – Stereo Mix/Mon Modes ..........16 2.3.1 Stereo Channel Format: ....................
  • Page 6 P a g e GPI Connector – HD15 Socket.................... 44 Remote Control Connector/ RS 422 - D9 Socket ..............44 DIP switch configuration functions – To be confirmed ............44 Notes ........................... 45 General Notes........................46 AVM TOUCH SERIES - Technical Specifications ............... 46 HD Standards Supported.....................

  • Page 7: Introduction

    AVM-T-MIX. In the event of either scenario, please feel free to contact TSL via your local reseller or directly on +44 1628-676221, asking for the TOUCH SERIES Product Manager.
  • Page 8 P a g e AVM-T-MIX User Handbook Version Three...

  • Page 9: Block Diagram

    P a g e Block Diagram AVM-T-MIX User Handbook Version Three...

  • Page 10: Operation

    Operation The AVM-T-MIX is designed to be user friendly and intuitive to operate. The menus and functions will feel familiar to both users of TSL multichannel audio monitoring products and those buying a TSL solution for the first time. Important Note: AVM-T-MIX ships with a default 0dBu reference level set to -18 dBFS, the default operating scale is EBU Digital.

  • Page 11: Controls And Displays - Overview

    P a g e | 11 2.0 Controls and Displays - Overview ‘Home’ Preset Dual Action Monitoring 4-Driver Level Control w/Cut, Dim Loudspeaker Instant Recall System CLEAN LIVE MIX 1 MIC1 COMMS LS RS INPUT MSTR C LFE Stereo Mono Dmix Rst Lvl SDI 1 pair 1...
  • Page 12 P a g e | 12 Touch and Hold Mix Master Input Channel Touch and Hold Bargraph to Select Mix 1 or Format Selection Bargraph for Mix 2 Input configurations Source Selection Level Send and Stereo/Mono/Group Individual Selected Channel Channel ‘Cut’ Bal/Pan Channel Status Status and ‘Solo’...
  • Page 13 P a g e | 13 Input Channels Unused Input with 10 Character Channels Routed to ‘No Input’ User Mnemonic Names Names Channel defined as ‘Mono’, Channel defined Selected Channel overview Channels defined as including ‘Input Source’, as Stereo format ‘Left Only’...

  • Page 14: Source Selection

    P a g e | 14 2.1 Source Selection Key to the ease of operation of AVM-T-MIX is the simplicity by which audio may be monitored and/or mixed. As described previously, AVM-T-MIX is equipped with two completely independent mixer/monitor systems (Mixer 1 and Mixer 2). Each can be configured with its own setup and used in diverse applications.

  • Page 15: Analogue Audio Input Trim

    P a g e | 15 2.2 Analogue Audio Input Trim AVM-T-MIX is designed to be used with balanced or unbalanced analogue audio inputs. If one of the analogue inputs has been wired to an unbalanced signal source then the user may need to compensate for signal loss (typically -6dB).

  • Page 16: Channel Signal Format Selection - Stereo Mix/Mon Modes

    P a g e | 16 2.3 Channel Signal Format Selection – Stereo Mix/Mon Modes Applicable to Stereo Output Mixer Formats Only Channel formats can be defined as Stereo, Mono or a Group of 2 or more pairs (including 5.1 and LRC Downmix configurations). 2.3.1 Stereo Channel Format: To define a channel as Stereo, simply touch the...

  • Page 17: Group Lrc Dmix

    P a g e | 17 the image above. In 5.1 Downmix mode the LFE channel does not form part of the stereo sum. The user can adjust the level of the left sum against right via the balance control. The 5.1 Downmix algorithm follows the formula L+(C-3dB) + (Ls-3dB), R+(C-3dB) + (Rs- 3dB).

  • Page 18: Group Channel Format

    P a g e | 18 2.4.3 Group Channel Format: The four modes previously described for stereo mixer use (2 pair ADD, 2 pair OFF, 5.1 DMIX and LRC DMIX) remain active when a 5.1 mixer mode is activated however an additional mode, 5.1 ALL, now appears under the Grouping menu.

  • Page 19: Monitoring Input Channels - Solo Function

    P a g e | 19 2.5 Monitoring Input Channels – Solo Function Similar to a traditional rackmount audio monitoring unit, the AVM-T-MIX is used to listen to incoming signal sources – either exclusively or additively. The simplest way to achieve this is to touch the bargraph channel you wish to hear and then to select SOLO.

  • Page 20: Monitoring Input Channels - Mixer Function

    P a g e | 20 2.6 Monitoring Input Channels – Mixer Function One of the unique advantages of AVM-T-MIX over a more traditional Audio Monitoring Unit is the ability to mix sources together using the same methods found in assignable digital audio mixing consoles.

  • Page 21: Audio Mixers 1 And 2

    P a g e | 21 2.7 Audio Mixers 1 and 2 The AVM-T-MIX is equipped with two identical but independent 20 channel (10 stereo bargraph) audio mixers designed to enable the operator to create their own custom monitoring setups. On first power up, AVM-T-MIX displays the bargraphs associated with Mixer 1 as denoted by the mnemonic MIX 1 MASTER above the output bargraph pair as shown below.

  • Page 22: Configuring And Naming Input Channels

    P a g e | 22 2.8 Configuring and Naming Input Channels The physical audio connections into AVM-T-MIX comprise of 16 channels from HD-SDI (16 channels SDI 1, 8 channels SDI 2)), 8 AES pairs and 16 (or 8 stereo) analogue audio inputs. Each pair can be routed to any of the 10 channel bargraphs available to either Mixer 1 or Mixer 2 and to simplify operation, each input pair can be given a User Name.

  • Page 23: X-Y Routing

    P a g e | 23 2.9 X-Y Routing  The XY router gives the user complete control over source to destination configuration. Any physical input or buss (mixer, monitor) can be assigned to any AES or analogue output connector ...
  • Page 24 P a g e | 24 Routing selection must always be performed in the order Select Output > Select Source > Take. By default any routing assignment is made in stereo however it is possible to route left or right signals independently using the following sequence Select Output >...

  • Page 25: Internal Sources

    P a g e | 25 2.9.2 Internal Sources An AVM-T-MIX Internal Source may be thought of as a type of router input that is derived within the mixer rather than a physical connection. The Internal Source list within the Touchmix includes the following; Mixer 1 –...

  • Page 26: Physical Sources

    P a g e | 26 2.9.3 Physical Sources Touchmix has a total of 64 available physical sources available taken from SDI, AES and Analog connections, of which 48 are available at any given time. Each pair can be selected as a stereo or left only, right only input and routed to any physical output using the routing procedure described later in this document.

  • Page 27: Routing Status 'Window

    P a g e | 27 Routing Status ‘Window’ 2.9.6 The text box in the centre of the AVM-T-MIX is a Routing Status indicator which provides a brief information summary of the highlighted route. The Routing Status Window indicates five fields of useful data;...

  • Page 28: Conditional Routing Rules

    P a g e | 28 The upper line of text in each ‘button’ shows the physical output connection and the lower line shows the currently routed source. 2.9.8 Conditional Routing Rules The user can choose from the Overview Page the way that the selected output manages particular types of audio.

  • Page 29: Routing System Xy Crosspoint Map

    P a g e | 29 2.10 Routing System XY Crosspoint Map The matrix below describes the components of the XY routing system as a crosspoint map with the input sources to the Y Axis and the outputs to the X Axis. The right hand block of blue crosspoints denotes the bargraph routing selection to the mixers 1 and 2 and their resultant mix and monitor outputs can be seen towards the bottom left represented as routable sources.

  • Page 30: User Preset And Snapshot Management

    P a g e | 30 2.11 User Preset and Snapshot Management 2.11.1 Home Button and User Presets AVM-T-MIX uses both internal and external User Preset memories to enhance usability, there are a total of 18 User Presets in local memory plus a Snapshot which is defined as HOME enabling operators to instantly revert to a default operational condition.
  • Page 31 P a g e | 31 Set User – Pressing the Set User button enables the operator to store the current operational configuration to any of the 18 internal memory locations. The following menu will appear; Simply select the desired internal memory location (User 1-18), enter a name using the QWERTY keyboard (press Clear to remove the default name) and Save to store.

  • Page 32: User Presets - Recall Menu

    P a g e | 32 2.11.3 User Presets – Recall Menu Pressing the HOME button momentarily accesses the Recall menu. This menu page allows the operator to recall saved snapshot memories, to recall memories from an external device and to instantly recall the HOME snapshot.

  • Page 33: Setup Menu

    P a g e | 33 2.12 Setup Menu Setup Menu includes options for different Scales, Reference Levels, Peak Hold, Input Naming, Output Routing, SDI Input Select, Mixer 1 mode and access to the Setup 2 Menu. By simply touching the appropriate button, individual sub menus are selected. 2.12.1 Meter Menu Pressing the Meter button accesses the bargraph scale options.

  • Page 34: Dbfs Menu

    P a g e | 34 2.12.2 dBFs Menu The dBFs parameter selection can be used to alter the 0dBu reference level from between -12 and -24 dBFs. 2.12.3 Meter Peak Menu The Peak parameter selects the offset level between the Reference dBFS setting and the onset of Peak indication (the point where the bargraph changes colour to red) from between +1dB and +18dB.

  • Page 35: Meter Hold Menu

    P a g e | 35 2.12.5 Meter Hold Menu AVM-T-MIX features a simple Peak Hold indicator which may be turned on and off using the Meter Hold Menu. 2.12.6 SDI Input Select A standard AVM-T-MIX has two SDI inputs that can be switched into a single de-embedder as illustrated by the block diagram towards the front of this handbook.

  • Page 36: Setup 2 Menu

    P a g e | 36 2.13 Setup 2 Menu Setup 2 Menu includes options to protect User Presets, GPI Action, External and Internal Loudspeaker Mute, Surround Downmix Coefficients, Monitor Mode and to access the Software Management Menu. 2.13.1 User Save Menu The User Save Menu enables an Engineer or Technician to Lock or Unlock the User Preset management system onboard AVM-T-MIX.

  • Page 37: Gpi Menu

    P a g e | 37 In Default mode the operator would normally hear the output of whichever mixer is currently shown on the touchscreen. The user can choose to hear either Mixer 1 or Mixer 2 permanently regardless of the mixer under direct control. 2.13.3 GPI Menu The GPI Menu enables an Engineer or Technician to select whether GPI inputs respond to Latching or Momentary closures from external devices.

  • Page 38: Surround Mix Menu

    2.14 Software Menu TSL is committed to providing customers with free life of product software updates as the features of AVM-T-MIX evolve and any bugs are addressed. New code is made available via our reseller distribution channels and as a download from the TSL website.
  • Page 39 P a g e | 39 In order to commence the upload sequence, simply press the UPDATE button and the FP4, FPGA, and PIC code will be loaded in order. Progress in indicated via the 0-100% scale. Once complete, AVM-T-MIX will display a message confirming that the process has been successfully concluded prompting the user to perform a factory reset.

  • Page 40: Connectivity And Pin-Out Details

    For unbalanced AES I/O connectivity an optional BNC breakout cable, CAB-D25-BNC, is available from TSL or your local reseller. When used in conjunction with AVM-T-MIX, DIP switch 2 (AES Impedance) must be switched to the 75 ohm position.

  • Page 41: Analogue Output Connector

    P a g e | 41 Analogue Output Connector D25 Socket Pinout on unit, Plug (shown) on mating cable. D 25 SOCKET AUDIO OUT ON AMU PIN NO FUNCTION A8+ (Var. Mon R) A8- (Var. Mon R) Ground A7+ (Var. Mon L) A7- (Var.

  • Page 42: Analogue Input Connectors 1-4 And 5-8

    P a g e | 42 Analogue Input Connectors 1-4 and 5-8 – D25 Socket Pinout on unit, Plug on mating cable. D 25 SOCKET AUDIO IN ON AMU PIN NO FUNCTION A4 (A8) R+ A4 (A8) R+ Ground A4 (A8) L- A4 (A8) L- Ground A3 (A7) R+...

  • Page 43: Aes Input/Output Connectors 1-4 And 5-8

    AES connectors may be wired using unbalanced terminations for SPDIF and 75R coaxial systems. Optional AES breakout cable CAB-D25-BNC-2 is available from TSL Sales (+44 1628 676200) and provides BNC Socket to D25 connectivity. Please note that when using AVM-T-MIX with unbalanced AES audio connections that the 75/110 ohm DIP Switch must be selected prior to use.

  • Page 44: Gpi Connector - Hd15 Socket

    P a g e | 44 GPI Connector – HD15 Socket. GPI pins are as follows: Dim - pin 6 Cut - pin1 Home - pin 11 User Preset 1 - pin 7 User Preset 2 - pin 2 User Preset 3 - pin 12 User Preset 4 - pin 8 User Preset 5 - pin 3 User Preset 6 - pin 13...

  • Page 45: Notes

    P a g e | 45 Notes There are no user adjustable assemblies/components within this unit. This unit requires rear support when rack mounted. In order to affect status changes of the unit using the rear DIP switch, the unit will require re powering before the changes take effect.

  • Page 46: General Notes

    General Notes Please note that some American equipment has the function of the XLR pins 2 & 3 reversed. TSL product is wired to the European standard The screw locks on the D25 connectors use UNC 4-40 standard threads. AVM TOUCH SERIES - Technical Specifications...

  • Page 47: Hd Standards Supported

    P a g e | 47 HD Standards Supported 1080i/50 1080p/23.98 1035i/30 1080i/59.94 1080p/24 1035i/29.94 1080i/60 1080p/25 1080sf/30 1080P/50 1080p/29.97 1080sf/29.97 1080P/59.94 1080p/30 1080sf/25 1080P/60 1080i/25 1080sf/24 720p/50 1080i/24.94 1080sf/23.98 720p/59.94 1080i/30 720p/60 480i/30.00 (SD - NTSC) 576i/25.00 (SD - PAL) Performance Response 70Hz to 20KHz...

  • Page 48: Installed Hdc-2T Audio Monitor Module Specification

    P a g e | 48 Installed HDC-2T Audio Monitor Module Specification 6.1.1 Overview This specification describes the HDC-2T Audio Monitor Module. This module has been designed to monitor a combination of analogue audio, AES3 digital audio and AES or Dolby E digital audio embedded in SMPTE 259M or SMPTE 292M video data streams, together with the video content which is output as composite and/or SDI.

  • Page 49: Loudspeakers

    P a g e | 49 Eight AES (16 channels) may be output from analogue audio, embedded audio. Connector type: 25way D-type 4 AES pairs (In and Out), pin-out as per Yamaha Standard Impedance: 75 unbalanced or 110 balanced. Impedance is switch selected with on-board transformer balancing.
