- Page 1 SGB100 BLUETOOTH COMMUNICATION MODULE USER MANUAL SMARTGEN (ZHENGZHOU) TECHNOLOGY CO.,LTD.
- Page 2 All rights reserved. No part of this publication may be reproduced in any material form (including photocopying or storing in any medium by electronic means or other) without the written permission of the copyright holder. SmartGen Technology reserves the right to change the contents of this document without prior notice. Software Version...
-
Page 3: Table Of Contents
SGB100 Bluetooth Communication Module User Manual CONTENTS OVERVIEW ........................4 PERFORMANCE AND CHARACTERISTICS ..............4 TECHNICAL PARAMETERS ..................4 SOFTWARE ........................4 SOFTWARE DOWNLOAD ..................4 SOFTWARE INSTALLATION REQUIREMENTS ............ 4 SOFTWARE FUNCTION DESCRIPTION ............... 4 OPERATION ........................6 BLUETOOTH CONNECT WITH CONTROLLER ............ 6 OPEN BLUETOOTH FUNCTION ON YOUR PHONE .......... -
Page 4: Overview
Storage Condition Temperature：(-25~+70)℃ 4 SOFTWARE 4.1 SOFTWARE DOWNLOAD Please download iGMPA6 mobile phone client-side from SmartGen official websites as below, http://www.smartgen.com.cn/datadownload.php http://www.smartgen.cn/datadownload.php 4.2 SOFTWARE INSTALLATION REQUIREMENTS Mobile phone and mobile device need to support Bluetooth 4.0 function and above android 4.3 version (4.7 inch or larger screen of mobile phone is recommended) - Page 5 SGB100 Bluetooth Communication Module User Manual Software Function Module: A. Module Config: Configure module’s parameters; B. Module Monitoring: Check engine information, input/output ports status, maintenance and electric quantity information. C. Data Calibration: Calibrate controller’s data and time, total run time, total start times and active electric energy.
-
Page 6: Operation
SGB100 Bluetooth Communication Module User Manual 5 OPERATION 5.1 BLUETOOTH CONNECT WITH CONTROLLER SGB100 Bluetooth communication module connects with controllers via USB port. 5.2 OPEN BLUETOOTH FUNCTION ON YOUR PHONE Open Bluetooth function on your phone: “Settings” -->”Bluetooth” SGB100 Bluetooth Communication Module Version 1.0... -
Page 7: Igmpa6 Connect To Blutooth Communication Module
SGB100 Bluetooth Communication Module User Manual 5.3 iGMPA6 CONNECT TO BLUTOOTH COMMUNICATION MODULE Click “Connection” in any page of iGMPA6 software to enter into “Connecting Bluetooth” interface, and then scan the surrounding Bluetooth. Click the name of device to connect and re-click to release connection. -
Page 8: Check Alarming & Warning Information
SGB100 Bluetooth Communication Module User Manual 5.4 CHECK ALARMING & WARNING INFORMATION Click in any page of iGMPA6 software to check the detail alarm and warning information. SGB100 Bluetooth Communication Module Version 1.0 2017-01-06 Page 8 of 16... -
Page 9: Modify Module Configuration
SGB100 Bluetooth Communication Module User Manual 5.5 MODIFY MODULE CONFIGURATION Configuration parameters of controller can be read into iGMP6 software through “Read Config” in menu page, and the modified parameters can be written into controller through “Write in Config”. “New Config” will initiate program parameters to the default value. - Page 10 SGB100 Bluetooth Communication Module User Manual Module configuration parameters can be modified through “Module Config”. (“Read Config” before modify parameters is recommended.) SGB100 Bluetooth Communication Module Version 1.0 2017-01-06 Page 10 of 16...
-
Page 11: Module Monitoring
SGB100 Bluetooth Communication Module User Manual 5.6 MODULE MONITORING Through module monitoring function, users can check electric quantity information, genset working status (including genset information, input/output port information and maintenance status), and also can control genset and transfer switch. Genset Status(include control operation) is as bellow,... -
Page 12: Data Calibration
SGB100 Bluetooth Communication Module User Manual 5.7 DATA CALIBRATION This function can calibrate controller’s data and time, total run time, total start times and active electric energy. SGB100 Bluetooth Communication Module Version 1.0 2017-01-06 Page 12 of 16... -
Page 13: Historical Data
SGB100 Bluetooth Communication Module User Manual 5.8 HISTORICAL DATA This function can read and clear controller’s historical data, and save the historical data to catalog of the phone my device/SmartGen/iGMPA6/history as the text file. SGB100 Bluetooth Communication Module Version 1.0... -
Page 14: Manage Configuration Files
SGB100 Bluetooth Communication Module User Manual 5.9 MANAGE CONFIGURATION FILES Configuration files in the phone’s catalog of my device/SmartGen/iGMPA6/history can be managed through “Software Set” ->”Configuration Files” function. Click each configuration file, and then it can “open in text file form” and “share the file”. -
Page 15: Manage Historic Record
SGB100 Bluetooth Communication Module User Manual 5.10 MANAGE HISTORIC RECORD Historic record files in the phone’s catalog of my device/SmartGen/iGMPA6/history can be managed through “Software Set” ->”Historic Record” function. Click each historic record file, and then it can “open in text file form” and “share the file”. -
Page 16: Attention
SGB100 Bluetooth Communication Module User Manual 6 ATTENTION 6.1 CONNECTION DELAY After iGMP6 connecting with Bluetooth device, it will establish a normal communication connection with the controller after 5s-7s. Otherwise, mobile phone can’t communicate with the controller. 6.2 PASSWORD If users want to change controller’s password, please select password option and enter the new password (default password appeared in the input box is not the real password of the controller).
