Smartgen HGM150 User Manual
  1. Manuals
  2. Brands
  3. Smartgen Manuals
  4. Control Unit
  5. HGM150
  6. User manual

Smartgen HGM150 User Manual

Genset control module
Hide thumbs
Table of Contents

Advertisement

Quick Links

HGM150 Genset Control Module
USER MANUAL
Smartgen Technology

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HGM150 and is the answer not in the manual?

Questions and answers

Imran safdar
March 3, 2025

How to start this module hgm150

0
1 comments:
Mr. Anderson
March 3, 2025

The Smartgen HGM150 module is controlled via pushbuttons on the front panel. To start the module, press the appropriate button on the panel. The module will monitor engine parameters and display any faults on the LED screen.

This answer is automatically generated

0

Related Manuals for Smartgen HGM150

Summary of Contents for Smartgen HGM150

  • Page 1 HGM150 Genset Control Module USER MANUAL Smartgen Technology...
  • Page 2 Applications for the copyright holder’s written permission to reproduce any part of this publication should be addressed to Smartgen Technology at the address above. Any reference to trademarked product names used within this publication is owned by their respective companies.

  • Page 3: Table Of Contents

    HGM150 Generator Control Module CONTENTS 1 SUMMARY ..................... 4 2 PERFORMANCE AND CHARACTERISTICS ..........4 3 SPECIFICATION .................... 4 4 PANEL OPERATION ..................5 5 TERMINALS FUNCTION ................6 6 TYPICAL APPLICATION ................7 7 CASE DIMENSIONS (Panel Cutout 78 mm*66mm) ........8 8 HGM170RE RELAY EXPANSION MODULE (Optional) ........

  • Page 4: Summary

    HGM150 Generator Control Module 1 SUMMARY HGM150 is an engine protection module designed to control the engine via pushbuttons on the front panel. When detecting failures, such as low oil pressure, high water/cylinder temperature, over speed and external alarm, it will initiate shutdown/alarm signal.

  • Page 5: Panel Operation

    HGM150 Generator Control Module Item Contents Case Dimensions 84mm x72mm x 35mm Panel Cutout 78mm x 66mm Operation Condition Temperature: (-30~+70)º C Humidity: (20~90)% Storage Condition Temperature：(-40~+80)º C IP55: when waterproof rubber gasket added between controller and its panel. Protection Level IP42: when waterproof rubber gasket not added between controller and its panel.

  • Page 6: Terminals Function

    HGM150 Generator Control Module the module power. If over speed indicator is flashing rapidly, it means that over speed threshold can be set. 2) Adjust engine speed to a specified over speed value, press , all indicators illuminate; over speed threshold is the current rotating speed.

  • Page 7: Typical Application

    HGM150 Generator Control Module (20~300) V AC, rated frequency is 50/60Hz. ◆ Terminal 11 (NC): Not connection. ◆ Terminal 13 (Over Speed Output): When module detects output frequency more than pre-setting over speed threshold, it will output and hold after 3s’...

  • Page 8: Case Dimensions (Panel Cutout 78 Mm*66Mm)

    HGM150 Generator Control Module 7 CASE DIMENSIONS (Panel Cutout 78 mm*66mm) 8 HGM170RE RELAY EXPANSION MODULE (Optional) HGM170RE is modular structure which can be fixed in various guides with compact structure, small size and easy installation. Expansion circuits output: 1. Fuel relay 30A, output voltage B+, coil power≤0.9W 2.

  • Page 9: Overall Demenions Of Hgm170Re

    HGM150 Generator Control Module 11 AUX OUT2 contact normally opens. interconnected control corresponding Stop relay control, connect to 12 STOP CTRL items. ground. 9 OVERALL DEMENIONS OF HGM170RE Note: When ordering please specify 12V or 24V. HGM150 Control Module ISSUE 2011-12-22 Version 1.3...
