CONTENTS
PRECAUTIONS
NOTES OF USE
NETWORKING
SPECIFICATIONS
WARNING:
Before attempting to connect or operate this product, read these instructions carefully.
Save this manual for future use.
To avoid electrical shock and to preserve the product warranty, DO NOT disassemble the camera.
Refer servicing to qualified personnel only.
Network Camera User Guide
C-AX401C1M
1
2
4
6
Advertisement
Related Manuals for i3 International C-AX401C1M
Summary of Contents for i3 International C-AX401C1M
- Page 1 C-AX401C1M Network Camera User Guide CONTENTS PRECAUTIONS NOTES OF USE NETWORKING SPECIFICATIONS WARNING: Before attempting to connect or operate this product, read these instructions carefully. Save this manual for future use. To avoid electrical shock and to preserve the product warranty, DO NOT disassemble the camera.
- Page 2 PRECAUTIONS This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 3 NOTES OF USE Power Supply Ensure the supplied voltage meets the power consumption requirements of this camera before powering the camera on. Incorrect voltage may cause irreparable damage to the video camera and will effectively void the camera warranty Operating or storage location Avoid shooting very bright objects (such as light fittings) for an extended pe- riod.
- Page 4 NOTES OF USE Included in the box Camera (C-Ax401PTZ) 4x Screws and 4x plugs for mounting Mounting template Quick start guide Mounting plate Feature & Functions Defaultb utton SD card SD card slot Resetb utton Poweri ndicator Networ k Audioo utput DigitalI /O 24VAC connector...
- Page 5 NETWORKING Connecting to a camera using a network 1. Connect the camera to a PoE (Power over Ethernet) enabled switch or router using a RJ45 Cat5 or Cat6 connection cable. 1.1. Connect the users computer to the PoE switch or router. 1.
- Page 6 NETWORKING 4. If you cannot connect try the following: 4.1. Wait. sometimes the router or switch will take a few seconds to refresh the routing table 4.2. Go to control panel, network connections, and properties of the LAN or WAN the camera is connected to. Under the Internet Protocol (TCP/IP) properties, change the 2nd section of the IP to match the same as your camera EG IP: 192.0.0.90 Camera: 192.0.0.64 Network connections...
- Page 7 SPECIFICATIONS Camera Scanning System Progressive Synch System Internal Image Sensor 1/4” Super HAD Resolution of Image Sensor MJPEG: VGA (640x480) / QVGA (320x240): 30fps MPEG4: VGA (640x480) / QVGA (320x240): 30fps Number of Effective Pixels 330K pixels, 640 (H) x 480 (V) Lens f=4.2~42 mm, F1.8 to 2.9 Frame rate...
- Page 8 SPECIFICATIONS Interface Network Port RJ45 with LEDs Audio IN & OUT Ports 3.5mm phone jack Alarm IN & OUT Ports 1x Alarm In / 1x Alarm out Electrical Audio Two-way mono audio; Full-duplex Alarm Yes, 2 x Alarm in, 1 x Alarm out SD card slot Yes, SD card up to 2GB supported Power Requirement...
- Page 9 i³ INTERNATIONAL INC. 1.866.840.0004 U.S.A. 440 Lawrence Bell Drive, Canada 780 Birchmount Road, www.i3international.com Suite 16, Williamsville Unit 16, Scarborough, NY, 14221 ON, M1K 5H4...
