Network Camera User Guide
C-AX401D1M
1
2
4
6
8
Advertisement
Related Manuals for i3 International C-AX401D1M
Summary of Contents for i3 International C-AX401D1M
-
Page 1: Table Of Contents
C-AX401D1M Network Camera User Guide CONTENTS PRECAUTIONS NOTES OF USE MOUNTING INSTALLTION NETWORKING SPECIFICATIONS WARNING: Before attempting to connect or operate this product, read these instructions carefully. Save this manual for future use. To avoid electrical shock and to preserve the product warranty, DO NOT disassemble the camera. -
Page 2: Precautions
PRECAUTIONS This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Notes Of Use
NOTES OF USE Power Supply Ensure the supplied voltage meets the power consumption requirements of this camera before powering the camera on. Incorrect voltage may cause irreparable damage to the video camera and will effectively void the camera warranty Operating or storage location Avoid shooting very bright objects (such as light fittings) for an extended pe- riod. -
Page 4: Default Button
NOTES OF USE Included in the box Camera (C-AxD1M) Guide Pattern for mounting Quick start guide BNC connector with attached cable 4x screws and 4x plugs for mounting Software CD Feature & Functions Reset Button Default Button SD card slot Alarm In(Red:In/Orange:GND) Power 24V AC... -
Page 5: Mounting Installtion
MOUNTING INSTALLATION Ceiling/Wall Mount Installation Step 1: Adhere the guide pattern to the installation surface. Drill one big and three small holes, using the template as a guide. Step 2: Feed the power cable, LAN cable and other cables through the hole. Step 3: Loosen the locking screw. - Page 6 MOUNTING INSTALLATION Ceiling/Wall Mount Installation (Continued) Step 5: Adjust the view angle Monitor out Step 6: Align the notch with position “P”. Rotate the cover clockwise to lock the cover to the base. Tighten the locking screw. Step 7: Turn on the Power The camera has no main power switch or button.
-
Page 7: Networking
NETWORKING Connecting to a camera using a network 1. Connect the camera to a PoE (Power over Ethernet) enabled switch or router using a RJ45 Cat5 or Cat6 connection cable. 1.1. Connect the users computer to the PoE switch or router. 1. - Page 8 NETWORKING 4. If you cannot connect try the following: 4.1. Wait. sometimes the router or switch will take a few seconds to refresh the routing table 4.2. Go to control panel, network connections, and properties of the LAN or WAN the camera is connected to. Under the Internet Protocol (TCP/IP) properties, change the 2nd section of the IP to match the same as your camera EG IP: 192.0.0.90 Camera: 192.0.0.64 Network connections...
-
Page 9: Specifications
SPECIFICATIONS Camera Synch System Internal Image Sensor 1/3" progressive transfer CCD Number of Effective Pixels Full scanning mode: 1280 (H) x 960 (V) Lens f=2.7~9mm, F1.2 Frame rate SVGA 1280x960 @ 15fps VGA 640x480, QVGA 320x240 @ 30 fps Motion detection Image Compression Method MJPEG / MPEG4 White Balance... - Page 10 SPECIFICATIONS Network Image compression method MJPEG / MPEG4 Protocol TCP/IP, UDP/IP, HTTP, SMTP, DNS, DHCP, NTP, DDNS, FTP, RTP Connectors 2-pin terminal block Interface Network Port RJ45 with LEDs Audio IN & OUT Ports 3.5mm phone jack Alarm IN & OUT Ports 1x Alarm In / 1x Alarm out...
- Page 11 i³ INTERNATIONAL INC. 1.866.840.0004 U.S.A. 440 Lawrence Bell Drive, Canada 780 Birchmount Road, www.i3international.com Suite 16, Williamsville Unit 16, Scarborough, NY, 14221 ON, M1K 5H4...
