2600W ANGLE GRINDER
MODEL NO: CON2600
PART NO: 6470145
OPERATION & MAINTENANCE
INSTRUCTIONS
LS0415

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CON2600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke CON2600

  • Page 1 2600W ANGLE GRINDER MODEL NO: CON2600 PART NO: 6470145 OPERATION & MAINTENANCE INSTRUCTIONS LS0415...
  • Page 2: Environmental Protection

    INTRODUCTION Thank you for purchasing this CLARKE 2600W Angle Grinder. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 3: General Safety Rules

    GENERAL SAFETY RULES 1) WORK AREA 1. Keep the work area clean and well lit. Cluttered and dark areas invite accidents. 2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
  • Page 4: Angle Grinder Safety Instructions

    4) POWER TOOL USE AND CARE 1. Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate which it was designed. 2. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
  • Page 5 5. Start up speed. Always allow the angle grinder to run up to full operating speed before applying it to the job. 6. Avoid operator fatigue. Stop the angle grinder at regular intervals for a short break to rest hands and arms. 7.
  • Page 6: Disc Safety Instructions

    DISC SAFETY INSTRUCTIONS 1. Disc speed. Check the speed of the disc before fitting to your angle grinder. Never use a disc with a rpm speed less than the rpm speed of your angle grinder. 2. Inspect the disc before fitting. Never use a disc that is chipped, cracked or damaged.
  • Page 7: Safety Symbols

    SAFETY SYMBOLS Wear a dust mask Wear ear protection Wear eye protection Wear protective gloves Not suitable for wet grinding Read instruction manual before use...
  • Page 8: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz.
  • Page 9 OVERVIEW DESCRIPTION NO DESCRIPTION Lock Off Lever Threaded hole (for the side handle) On/Off Trigger Switch Rear Handle Release button Disc Guard Rear Handle Grinding/Cutting Disc Mains Lead Direction of Rotation Indicator Air Vents Spindle Lock Button Side Handle...
  • Page 10: Before Use

    BEFORE USE FITTING / ADJUSTING THE DISC GUARD WARNING: MAKE SURE THAT THE ANGLE GRINDER IS SWITCHED OFF AND UNPLUGGED FROM THE MAINS SUPPLY BEFORE FITTING OR REMOVING ANY ACCESSORIES. 1. Slide the disc guard into place as shown. 2. Rotate the disc guard to the required position and secure by tightening the cap head screw using the hexagonal key supplied.
  • Page 11: Fitting And Removing A Disc

    FITTING AND REMOVING A DISC WARNING: MAKE SURE THAT THE ANGLE GRINDER IS SWITCHED OFF AND UNPLUGGED FROM THE MAINS SUPPLY BEFORE FITTING OR REMOVING ANY ACCESSORIES. 1. Make sure the disc guard is fitted before you fit any cutting/grinding disc. 2.
  • Page 12: Fitting The Side Handle

    FITTING THE SIDE HANDLE 1. Fit the side handle by screwing it into one of the 3 threaded holes on the angle grinder. ADJUSTING THE REAR HANDLE The rear handle can be rotated to give a more comfortable grip. 1. Hold the body of the angle grinder with one hand.
  • Page 13: Using Your Angle Grinder

    USING YOUR ANGLE GRINDER WARNING: FRAGMENTS FROM A BROKEN/DETACHED DISC CAN CAUSE SERIOUS INJURY. WARNING: WHEN USING CUTTING DISCS, DO NOT STAND DIRECTLY IN LINE WITH THE ROTATING DISC. WARNING: DO NOT PUT SIDEWAYS PRESSURE ON CUTTING DISCS. WARNING: ENSURE THAT THE WORKING POSITION ADOPTED DOES NOT CAUSE OPERATOR FATIGUE WHICH MAY LEAD TO LOSS OF CONTROL OF THE CUTTING DISC AND IMPACT/SNATCH WITH SURROUNDING OBJECTS/ MATERIALS.
  • Page 14: Cutting Tips

    CUTTING TIPS • Do not force the disc through the material. Work with a feed rate that is suited to the material being cut. • Do not subject the cutting disc to sideways pressure. • The direction of the cutting motion is important. Always feed the cutting disc into the work so that it cuts in an upward direction.
  • Page 15: Maintenance

    MAINTENANCE CHANGING THE CARBON BRUSHES 1. Remove the screw holding the brush cover in place. 2. Remove the screw and washer holding the braid in place. 3. Hold back the spring assembly, and slide out the carbon brush. 4. Replace with the new brush supplied.
  • Page 16: General Maintenance

    PARTS AND SERVICING There are no user serviceable parts in this angle grinder, all servicing and repairs should be carried out by your nearest Clarke dealer. For Parts & Servicing, please contact your nearest dealer, or CLARKE International, on one of the following numbers.
  • Page 17 OVERVIEW...
  • Page 18 DESCRIPTION PART NUMBER NO DESCRIPTION PART NUMBER Top Flange KPCON260001 Ring KPCON260033 Grinding Wheel KPCON260002 Screw KPCON260034 Bottom Flange KPCON260003 Stator KPCON260035 Guard KPCON260004 Decorative Card KPCON260036 Bolt KPCON260005 Housing KPCON260037 Screw KPCON260006 Spring KPCON260038 Screw KPCON260007 Brush Holder KPCON260039 Gear Box Cover KPCON260008 Brush...
  • Page 19: Declaration Of Conformity

    DECLARATION OF CONFORMITY...
