Project 122

Place all the parts on the base grid then assemble the parts on the two 90 degree

vertical snap wires (V1). Install the egg on the color2 LED (D12).

Turn on the slide switch (S1). The LEDs and lamp all light as the egg changes colors.

Project 123

Place the parts on the base grid, then mount the 3-snap wires and lights on the 90 degree

vertical snap wires (V1), then add the 3D snaps and orange motor (M9), then add the 45

degree vertical snap wires (V2), then place the mirror ball on the orange motor.

Turn the switch on, the robot's head spins and his body light up.

Egg Head

Robot

-72-
