Elenco Electronics SCROV-10 Instruction Manual

Electronic snap circuits, rc snap rover projects 1-23
Hide thumbs
Table of Contents

Advertisement

Quick Links

Copyright © 2006 by Elenco
®
Electronics, Inc. All rights reserved. No part of this book shall be reproduced by
753131
any means; electronic, photocopying, or otherwise without written permission from the publisher.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCROV-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elenco Electronics SCROV-10

Summary of Contents for Elenco Electronics SCROV-10

  • Page 1 Copyright © 2006 by Elenco ® Electronics, Inc. All rights reserved. No part of this book shall be reproduced by 753131 any means; electronic, photocopying, or otherwise without written permission from the publisher.

  • Page 2: Table Of Contents

    Warning to Snap Circuits Owners: Do not use parts from other Snap Circuits sets with this kit. The Snap Rover uses higher voltage which could damage those parts. Page 22 and our web site www.snapcircuits.net has approved circuits that you can use.

  • Page 3: Parts List

    Parts List (Colors and styles may vary) Symbols and Numbers Note: If you have a more advanced model, there are additional part lists in the other project manuals. Important: If any parts are missing or damaged, DO NOT RETURN TO RETAILER. Call toll-free (800) 533-2441 or e-mail us at: help@elenco.com.
  • Page 4 Antenna Front of Rover – The R/C Snap Rover Kit uses building blocks with snaps to build the different electrical and electronic circuits in the projects. Each block has a function: there are switch blocks, LED blocks, different length wire blocks, etc. These blocks are in different colors and have numbers on them so that you can easily identify them.

  • Page 5: About Your Snap Circuits Parts

    Warning to Snap Circuits owners: Do not use parts from other Snap Circuits sets with this kit. The Snap Rover uses higher voltage which could damage those parts. Page 22 and our web site www.snapcircuits.net has approved circuits that you can...

  • Page 6: How It Works

    How It Works Remote Control Transmitter: When the levers in the Remote Control Unit are pushed, electrical contacts are made connecting the 9V battery power to the transmitter, indicating which commands the user wants sent to the Rover. Forwards/Backwards commands for each set of wheels and two extra functions are controlled by different levers or buttons.

  • Page 7: General Operating Instructions

    (S1) to ON, and extend the antenna on the Remote Control. Push both levers forward to make Snap Rover go forward. Push both levers backward to go backward. Push the left lever backward and the right lever forward to turn left.

  • Page 8: Do's And Don'ts Of Building Circuits

    Warning to Snap Circuits owners: Do not use parts from other Snap Circuits sets with this kit except for the circuits on page 22. The Snap Rover uses higher voltage which could damage those parts. Our web site www.snapcircuits.net also has approved circuits that you can use.

  • Page 9: Advanced Troubleshooting

    Advanced Troubleshooting Elenco ® Electronics is not responsible for parts damaged due to incorrect wiring. If you suspect you have damaged parts, you can follow this procedure to systematically determine which ones need replacing: Rover body and jumper wires: Flip the Rover body upside down and make sure the wheel mechanisms are clean.

  • Page 10: Project 1

    The left button on the remote control activates the horn (W1). You can use Snap Rover in a dark room since the LED (D4) is positioned as a headlight. Spin Snap Rover around and use caution when backing up.

  • Page 11: Project 2

    Project #2 Note Install six (6) “AA” batteries into the bottom of the Rover body and one 9V battery into the remote control unit (batteries not included). Install the antenna in to the remote control unit by screwing it in. Place the base grid on the Rover body;...

  • Page 12: Projects 3, 4

    Build the circuit, place the base grid centered on the Rover body, and connect the jumper wires as shown. Place the Snap Rover in the middle of a dimly lit room and turn on the slide switch (S1). The light will shine around the room as Snap Rover spins.

  • Page 13: Projects 5, 6

    Project #5 Note Project #6 Rover Rear REAR ROVER (upside down) Two-Sound Rover OBJECTIVE: To build a remote control vehicle with two sound l e v e l s . Build the circuit shown and turn on the slide switch (S1). Turn on the remote control unit, extend the antenna, and use the levers try to drive the Rover around.

  • Page 14: Project 7, 8

    Project #7 Note Project #8 Note Rover rear (upside down) -13- OBJECTIVE: To learn about Morse code. Build the circuit, connect the jumper wires, and turn on the slide switch (S1). Turn on the remote control unit and extend the antenna. Press the buttons on the remote control to generate long or short bursts of sound (from the W1 horn) or light (from the D4 LED).
  • Page 15 Project #9 Note Project #10 Note Slow Turn-Off OBJECTIVE: To show how capacitors slow things down. Build the circuit, place the base grid on the Rover body, and connect the jumper wires as shown. Turn the swtch (S1) on and the LED is on.
  • Page 16 Project #11 Project #12 Note -15- OBJECTIVE: To b u i l d a c i r c u i t w i t h s o u n d a n d l i g h t . Note Electricity Bank OBJECTIVE: To show how capacitors store electrical charge.
  • Page 17 Project #13 Note Project #14 Note Note Note Slow R/C Flashlight OBJECTIVE: To b u i l d a r e m o t e c o n t r o l l i g h t . Build the circuit shown and turn on the slide switch (S1).
  • Page 18 Project #15 Project #16 -17- When More Are Less OBJECTIVE: To c o m p a r e t y p e s o f c i r c u i t s . Note When More Are More OBJECTIVE: To c o m p a r e t y p e s o f c i r c u i t s . Note Build the circuit and connect the jumper wires as shown.
  • Page 19 Project #17 Note Project #18 Note Note Pencil Buzz OBJECTIVE: To draw a missing component. Build the circuit at left and connect the jumper wires to it, but leave the loose ends of the green and purple jumpers unconnected for now. There is one more part you need and you are going to draw it.
  • Page 20 Project #19 Note Project #20 -19- Water Detector OBJECTIVE: To show how water conducts electricity. Build the circuit at left and connect the jumper wires to it, but leave the loose ends of the green and yellow jumpers lying on the table initially. Turn on the slide switch (S1) - the LED (D4) will be dark because the air separating the jumpers has very high resistance.
  • Page 21 Project #21 One-Way Light OBJECTIVE: To show how an LED works. Note Project #23 Project #22 OBJECTIVE: d e t e c t s t h e c o n d u c t i o n o f e l e c t r i c i t y i n Build the circuit, place the base grid d i ff e r e n t m a t e r i a l s .

  • Page 22: Other Snap Circuits Products

    OTHER SNAP CIRCUITS PRODUCTS! Contact Elenco Snap Circuits Jr. Snap Circuits Pro Musical Recorder FM Radio Model SCP-01 Model SCP-02 -21- ® to find out where you can purchase these products. Model SC-100 Build over projects Including: • Flying saucer •...
  • Page 23 If you own Snap Circuits Models SC-300, SC-500, or SC-750 (with 300+ experiments), then you may also build these circuits. Our web site (www.snapcircuits.net) has additional circuits. DO NOT use parts from other Snap Circuits kits with your Snap Rover except in our approved circuits - the Snap Rover uses higher voltage which could damage those parts.
  • Page 24 SCROV-10 Snap Rover Block Layout Important: If any parts are missing or damaged, DO NOT RETURN TO RETAILER. Call toll-free (800) 533-2441 or e-mail us at: help@elenco.com. Customer Service • 150 Carpenter Ave. • Wheeling, IL 60090 U.S.A. 7 x1 6 x1 (847) 541-3800 •...
