Project 60

Project 61

Use the preceding circuit, but remove the

melody IC (U32). You can also re-arrange

the lights.

Both Sides Lights

Project 62

Assembly:

1. Place base grid supports on base grid A.

2. Place parts base grids B, then install grid

B into base grid supports on grid Grid B

must be the two-sided grid.

3. Place the remaining parts on grid A.

Turn on the slide switch (S1) to light the

LEDs (D9, D11, & D12) and lamp (L4), and

play a melody.

Build the circuit, place the gear

insert on the orange motor (M9),

then lay the magnet so it is

centered on the gear insert. Turn

on the slide switch (S1). The

orange motor slowly spins the

magnet, activating the blue LED

(D9) as the magnet passes over

the reed switch (S9).

-50-
