Tall Angled Rood House Variants
Use the preceding circuit, but carefully replace the lamp (L4) with the melody IC (U32), clear
motor (M4, with green fan), or one of the LEDs (D9, D11, or D12). The "+" side should be to
the left.

Enhanced Tall Angled Roof House

-41-
Project 49
Project 50
Use the preceding circuit, but
carefully change the parts on
grid D to match the circuit
shown here.
Project 51
Enhanced Tall Angled Roof
House Variants
Use the preceding circuit, but carefully rearrange any of the lights, or replace them
with the melody IC (U32) or clear motor (M4, with green fan). "+" side should always
be on the left. Exception: do not replace the color2 LED (D12) with the clear motor,
because vibration could cause the Motor to come loose and fall.
Underside
view
