BikeErg Assembly Instructions
1

Lay out all parts as shown.

1. Box frame assembly
2. Crank arm with pedal
3. Rear leg with seat post and saddle
4. Handlebar assembly
5. Front leg with handlebar post
6. Performance Monitor 5 (PM5)
7. Rear foot
8. Front foot with casters
(16) 3/4" (1.9 cm)
PN 1201
with patch
(4) 3/4" (1.9 cm)
PN 1248
without patch
(2) 3" (1.9 cm)
PN 1267
PN 2230
2
Lay the box frame assembly
notch as shown. Attach the front leg
is routed properly and not pinched. IMPORTANT: To assure that screws are properly aligned and threads are engaged,
please insert all screws by hand, and get them started, before tightening any screws. This practice should be done at
every step of assembly.
(2) 3/4" (1.9 cm)
PN 1201
(2) 3" (7.62 cm)
PN 1267
2
6
5
8
on the floor and with the flywheel facing down. Route the monitor cable through the
to the box frame assembly using four fasteners. Check that the monitor cable
4
1
2
3/4" (1.9 cm)
PN 1201
3
7
3" (7.62 cm)
PN 1267
