Description
Meter Description
1. Probe Connection
2. LCD Display
3. HOLD Button
4. POWER Button
5. REC Button
6. ZERO Button
7. MODE DC/AC/SET Button
8. Tilt‐Stand and battery compartment on rear
9. Reset Button
10. DC 9V Power Adapter jack
Probe Description
1. Probe Sensing Head
2. Probe Handle
3. Probe cable
4. Probe Head Cover
Fig. 1 – Meter Description
1
3
1
2
3
4
5
6
7
8
2
Fig. 2 – Probe Description
4
