Module Selection Information
Master Controller Upgrades for Existing 4020 Series Fire Alarm Control Panel
Model Description
4020 Master Controller Upgrade to 4100ES; Includes New Master Controller with LCD & operator interface assembly,
8 VDC Converter and RUI Interface in a single bay cabinet with locking glass door and retainer; mounts as an adjunct
4100-9833
panel close-nippled to existing 4020 cabinet; also includes 8 VDC box-to-box power and communications harness and
solid filler panel for the existing 4020 Master Controller bay
Communication Modules
Model Description
4100-6078 For Master Controller; mounts in Slot 3
4100-6061 For Redundant Master Controller
4100-6056 Wired Media Module
4100-6057 Fiber Optic Media Module
4100-6047 Building Network Interface Card (BNIC), refer to data sheet S4100-0061 for details
Network Access Dial-in Service Modem, mounts to 4100-6078 or 4100-6061 Network
4100-6055
Interface Card, requires telephone line connection
4100-1291 Remote Unit Interface Module (RUI); up to three maximum per control panel
Service Port Modem, local panel access only, mounts to Master Controller Module,
4100-6030
requires telephone line connection, accesses same information as front panel port
4100-6031
Select one per
4100-6032
SPS (fits on SPS)
4100-6033
4100-6101 Physical Bridge, Class B, includes 1 modem module and 2 wired modules
4100-6102 Physical Bridge, Class X, includes 2 modem and 2 wired modules
4100-6038 Dual Port RS-232 with 2120 interface (slot module)
4100-6046 Dual Port RS-232 standard interface (4 x 5 module)
4100-6045 Decoder Module
4100-6048 VESDA Aspiration System Interface
DACT, Point or Event Reporting; 1 shipped unless 4100-7908 is selected; 2 max. per
4100-6052
system; includes 2, 2080-9047 cables, 14 ft (4.3 m) long, RJ45 plug and spade lugs
Expansion, System, Remote, and TrueAlert Power Supplies and Accessories
Model Voltage/Listing
4100-5101 120 VAC
4100-5103 120 VAC, Canadian
4100-5102 220-240 VAC
4100-5115 NAC Expansion Module, 3 NACs, Class A/B, mounts on XPS only
4100-5111 120 VAC
4100-5112 120 VAC, Canadian
4100-5113 220-240 VAC
4100-5125 120 VAC
4100-5126 120 VAC, Canadian
4100-5127 220-240 VAC
4100-5120 120 VAC
4100-5121 120 VAC, Canadian
4100-5122 220-240 VAC
4100-5124 TrueAlert SLC Class A Adapter for all 3 SLCs, mounts on TPS only
4100-5152 12 VDC Power Option, 2 A maximum
4100-0156 8 VDC Converter, required for multiple Physical Bridge Modules, 3 A maximum
4009 TPS Transponder Interface Card (TIC), mounts in a remote cabinet with TPS; order card, TPS, and batteries
4009-9813 separately, and select a 2975-9229 (red) or 2975-9230 (beige) cabinet (field installed); refer to data sheet S4100-0037
for cabinet detail; Supervisory and Alarm current = 87 mA; (CSFM listed under 7300-0026:0368)
4100-0636 Box Interconnection Harness Kit (non-audio); order one for each close-nippled cabinet
4100-0638 4100 Slot Module Additional 24 VDC Harness; need when 4100 Slot module requirements exceed 2 A from SPS
8 Zone Initiating Device Circuits*
Model Type Supv.
4100-5005 Class B 75 mA
4100-5015 Class A 75 mA
* IDC Modules are 1 Slot size
Continued on next page
Modular Network Interface; each requires
two media modules (below)
Select two media cards as required; mounts on
4100-6078 or 4100-6061
City Circuit, with disconnect switches
City Circuit, w/o disconnect switches
Alarm Relay, 3 Form C relays, 2 A @ 32 VDC; for SPS or RPS
Description
UL
Expansion Power Supply (XPS); 9 A output, 3 built-in
Class A/B NACs; NAC operation is same as SPS, see
ULC
page 5 for details
UL
UL
Additional System Power Supply (SPS); 9 A power
supply/charger with 250 point IDNet channel, 3 Class
ULC
A/B NACs, add IDNet device currents separately
UL
UL
Remote Power Supply (RPS); 9 A power
ULC supply/charger similar to SPS except no IDNet channel
or City Circuits; will accept one 4100-6033
UL
TrueAlert Power Supply (TPS); 3 Class B SLCs rated
UL
3 A each for up to 63 TrueAlert addressable (special
ULC application) appliances per channel, 189 per TPS;
built-in battery charger; 2 A aux. power output; add
UL
device current separately (see S4009-0003 for details)
Expansion Signal Module and Options
Alarm Model Description
195 mA 4100-5116 Converts 1 NAC in to 3 NACs out; 1 Block size
195 mA 4100-1266 Expands 3 NACs to 6
4100-1267 Converts 3 NACs to Class A
For use with SPS
only, not RPS
3 maximum of RS-232 type
modules per panel
(Canadian models have low battery cutout)
(1.5 A Class B except as noted)
select one; mounts
on 4100-5116
6
Size Supv. Alarm
1 Slot 46 mA 46 mA
1 Slot 46 mA 46 mA
N.A. 55 mA 55 mA
N.A. 25 mA 25 mA
2 Blocks 291 mA 291 mA
N.A. 60 mA 60 mA
1 Slot 85 mA 85 mA
N.A. 70 mA 70 mA
N.A. 20 mA 36 mA
N.A. 20 mA 36 mA
N.A. 15 mA 37 mA
1 Slot 210 mA 210 mA
2 Slots 300 mA 300 mA
1 Slot 132 mA 132 mA
1 Block 60 mA 60 mA
3 Slots 85 mA 163 mA
1 Slot 132 mA 132 mA
1 Slot 30 mA 40 mA
Size Supv. Alarm
2 Blocks 50 mA 50 mA
N.A. 25 mA 25 mA
4 Blocks 175 mA 185 mA
4 Blocks 150 mA 185 mA
4 Blocks 88 mA 100 mA
N.A. 10 mA 10 mA
1 Block 1.5 A maximum
1 Block included w/loads
Supv. Alarm
18 mA 80 mA
0.6 mA 60 mA
0.6 mA 30 mA
S4100-0031-21 12/2012
