Reverse Function; V-Mix - Fly Sky FS-i4X Instruction Manual

Throttle (Right Stick Up/Down)
THROTTLE UP
THROTTLE DOWN

5.2 Reverse Function

Channels 1-4 can be reversed, to reverse a channel:
• 1. Test the servo/throttle to make sure that the action corresponds as expected with the transmitters
controls.
• 2. If the direction of travel is wrong then toggle corresponding switch located at the bottom of the
transmitter, labled as RUD (Rudder), THR (Throttle), ELE (Elevator), AIL (Aileron). Up position being
reverse and down position being normal.
• 3. Test the servos again to make sure the direction of travel is correct.

5.3 V-MIX

The V-MIX function (5.6) is used for models that have no rudder.
No rudder: Creates a mix between channels 1 and 2, ailerons and elevators.
15
