System Customization; Switching Channel Asignments - Fly Sky FS-i4X Instruction Manual

Digital proportional radio control system

6. System Customization

The FS-i4X's switches and knobs can be moved
to other channels. Or if using receivers with more
channels, the system can be expanded with extra
switches or knobs.
By default, from left to right, the switches and knobs
are channels 5, 6, 7, 8, 9 and 10.
FS-A6/FS-iA6B 4CH, 5CH, 6CH
FS-iA10B 4-10CH

6.1 Switching Channel Asignments

To change a switch or knobs channel, the system
must be taken apart. The first step is taking the back
cover off.
• 1. Remove any batteries from the system and
replace the battery cover.
•
• 2. Remove the screws market in green.
Note: Make sure the screw driver you are using
is not too big or too small. Failure to do so could
damage the head of the screw.
• 3. Carefully pry the front and back apart, this
may take some force.
Note: Don't pull the pieces too far apart, doing so
could damage cables attacking the front and back
together.
• 4. Carefully disconnect the cables connecting the front to the back.
16
6 7 8
5
9
10
