- Page 1 FS-l6S Digital proportional radio control system INSTRUCTION MANUAL Digital proportional radio control system WARNING: Copyright ©2013-2017 This product is only for 15 years old or above Flysky RC model technology co., ltd...
- Page 2 Thank you for purchasing our product, an ideal radio system for beginners or experienced users alike. Read this manual carefully before operation in order to ensure your safety, and the safety of others or the safe operation of your system. If you encounter any problem during use, refer to this manual first.
-
Page 3: Table Of Contents
6.7 Output Mode ..............................18 6.8 Sticks Mode ..............................18 6.9 Factory Reset ..............................18 6.10 Firmware Update ............................18 6.11 Receiver Update ............................18 6.12 About FS-i6S..............................19 6.13 Timers ................................19 7. Product Specifications ........................20 7.1 Transmitter Specifications ...........................20 7.2 Receiver Specifications ..........................20 7.3 Receiver PPM Output ...........................20 8. - Page 4 This page is intentionally left blank.
-
Page 5: Safety
FS-l6S Digital proportional radio control system 1. Safety 1.1 Safety Symbols Pay close attention to the following symbols and their meanings. Failure to follow these warnings could cause damage, injury or death. Danger • Not following these instructions may lead to serious injuries or death. Warning •... - Page 6 • Misuse of this product may lead to serious injury or death. To ensure the safety of you and your equipment, read this manual and follow the instructions. • Make sure the product is properly installed in your model. Failure to do so may result in serious injury.
-
Page 7: Introduction
FS-l6S Digital proportional radio control system 2. Introduction The FS-i6S transmitter and FS-iA6B receiver constitute a 10 channel 2.4GHz AFHDS 2A digital proportional computerized R/C system. This system supports quadcopters. 2.1 System Features The AFHDS 2A (Automatic Frequency Hopping Digital System Second Generation) developed and patented by FLYSKY is specially developed for all radio control models. -
Page 8: Transmitter Overview
Phone Holder 2.2 Transmitter Overview Mounting Point Left Gimbal Right Gimbal Neck Strap Eye Power Button Power Button Capacitive Touch Screen Handle Key 1 Key 2 Battery Cover PS/2 Port USB Port... -
Page 9: Transmitter Antenna
FS-l6S Digital proportional radio control system 2.2.1 Transmitter Antenna Precautions: • For best signal quality, make sure that the antenna is at about a 90 degree angle to the model. Do not point the antenna directly at the receiver. • Never grip the transmitter antenna during operation. -
Page 10: Usb Simulator Mode
2.4 USB Simulator Mode The system may be used as a HID controller when connected to a computer via USB. When connected to a computer the function is activated automatically and will be recognized by windows as a game controller. To calibrate or test the system in windows: •... -
Page 11: Getting Started
FS-l6S Digital proportional radio control system 3. Getting Started Before operation, install the battery and connect the system as instructed below. 3.1 Transmitter Battery Installation Danger • Only use specified battery. Danger • Do not open, disassemble, or attempt to repair the battery. Danger •... -
Page 12: Operation Instructions
4. Operation Instructions After setting up, follow the instructions below to operate the system. 4.1 Power On Follow the steps below to turn on the system: Check the system and make sure that: • The batteries are fully charged and installed properly. •... -
Page 13: Power Off
FS-l6S Digital proportional radio control system 4.4 Power Off Follow the steps below to turn off the system: Disconnect the receiver power. Hold the transmitter's power buttons to turn off the transmitter. • Make sure to disconnect the receiver power before turning off the transmitter. Danger Failure to do so may lead to damage or serious injury. -
Page 14: Home Screen
5. Home Screen The home screen diplays useful information about your model, including timers, fly mode and TX/RX status. Start Page Timers + Timer Menu TX/RX Battery Status + Battery Setup Menu Fly Mode Status + Fly Mode Setup Menu Main Menu Display Servos Press and hold the screen to preform... -
Page 15: Fly Mode
FS-l6S Digital proportional radio control system 5.1 Fly Mode This mode can store settings that can be recalled by toggling a switch. There are several options available: • A: Stores the channel used by the flight controller. • Touch the box to the right of the desired channel. •... -
Page 16: Function Settings
6. Function Settings 6.1 Reverse Function The reverse function changes a channels direction of movement in relation to its input. For example, if the blades are spinning in the wrong direction, pushing the model into the ground instead of taking off, this function can be used to correct this. Setup: To change between normal and reverse touch the box to the right side of the desired channel. -
Page 17: Aux Channels
FS-l6S Digital proportional radio control system 6.4 Aux Channels The auxiliary channels can be used to control additional part of a model such as landing gear or lights. Select channels using the left or right arrow keys on the screen on either side of the channel name. The left box below the channel name allows the user to pick the type of control for that channel, Nul, VRx, MRx, KEY and SWx. -
Page 18: Bright ./Sound
Setup: If the mix is not already disabled turn it off by touching the box labeled "on". Select a master by touching the box to the right of the master channel and choose a channel from the list. Select a slave by touching the box to the right of the slave channel, then choose a channel from the list. -
Page 19: Sticks Mode
FS-l6S Digital proportional radio control system 6.8 Sticks Mode The system has 4 stick modes to change from, to change the mode touch M1, 2, 3 or 4 on the right hand side of the screen. The currently selected mode is highlighted in black. Mode 1 Mode 2 Left stick... -
Page 20: About Fs-I6S
6.12 About FS-i6S This menu shows the product name, firmware version, firmware release date, hardware version and the transmitter ID. 6.13 Timers To enter the timer function touch T1/T2 on the main screen. The system has 2 timers available, both can be assigned to a switch and have 3 different settings. -
Page 21: Product Specifications
FS-l6S Digital proportional radio control system 7. Product Specification 7.1 Transmitter Specification (FS-i6S) Channels Model type Quadcopter RF range 2.4055 ～ 2.475 GHz Bandwidth 500 KHz Band RF power Less then 20 dBm 2.4G system AFHDS 2A Code type GFSK Sensitivity... -
Page 22: Package Contents
8. Package Contents Product Quantity FS-i6S FS-iA6B or FS-iA10B Micro USB Cable Mobile Phone Holder (Optional) Sensors: (Optional) • FS-CPD01 • FS-CPD02 • FS-CTM01 • FS-CVT01 User Manual... -
Page 23: Fcc
FS-l6S Digital proportional radio control system 9. Appendix 1 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of theFCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 24 Digital proportional radio control system http://www.flysky-cn.com Copyright ©2013-2017 Flysky RC model technology co., ltd Edition: 2015-9-1...
