Page 1: Maintenance Instructions
Installation, Operation, and Maintenance Instructions Electric/Seletronic Griddle-Marine Models 124S-M 136S-M 148S-M 160S-M 172S-M Star Manufacturing International 10 Sunnen Drive St. Louis, MO.63143-3800 Part Number: 2M-W354 Ph: 314-781-2777 Fax: 314-781-2714 WWW.STAR-MFG.COM Rev.B May 31, 2007... -
Page 2: Notice
NOTICE THIS SUPPLEMENT IS FOR MARINE INSTALLED EQUIPMENT ONLY. THIS EQUIPMENT IS APPROVED FOR INSTALLATION ONLY ON VESSELS GREATER THAN 65 FEET IN LENGTH, IN ACCORDANCE WITH USCG REGULATIONS IN TITLE 46 CFR 110-113. ANY WIRING USED IN THE INSTALLATION OF THIS APPLIANCE MUST BE STRANDED COPPER. -
Page 3: Precautions/Information
Safety CAUTION: THE GRIDDLE IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF INSTALLATION. - Page 4 WARNING AND FOLLOW THE DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED. NOTICE: Service on this or any other Lang appliance must be performed by qualified personnel only. Consult your Lang Authorized Service Agent Directory. You can call our toll free number 1-800-807-9054 or visit our website for the service agent nearest you.
-
Page 5: Table Of Contents
Table of Contents Notice..............2 Precautions/Information.......... 3 Table Of Contents........... 5 Equipment Description..........6 Unpacking ............... 7 Installation............... 8 Initial Start-Up ............10 Operation ..............11 Cleaning..............12 Troubleshooting ............13 -14 Parts List ..............15 - 18 Wiring Diagram ............19 Cruise Line Warranty .......... -
Page 6: Equipment Description
Equipment Description Exterior Construction The griddle dimensions are 17". (43.18cm) High, 30" (76.20cm) deep, and width depends on the actual model number. The sides, bottom, and rear wall are constructed of double wall stainless steel, which allows closer installation to combustible surfaces. -
Page 7: Unpacking
Unpacking Receiving the Griddle Upon receipt, check for freight damage, both visible and concealed. Visible damage should be noted on the freight bill at the time of delivery and signed by the carrier's agent. Concealed loss or damage means loss or damage which does not become apparent until the merchandise has been unpacked. -
Page 8: Installation
Installation THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL DANGER PROVIDED. FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH. INSTALLATION OF THE UNIT MUST BE DONE BY WARNING PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. -
Page 9: Electrical Connection
Installation Electrical Connection There is one power supply connection on the 24, 36, and 48-inch griddles. There are two power supply connections on 60 and 72-inch griddles. Refer to the power supply chart below, for proper power supply size. There is (1) one 1 1/4-inch conduit knockout on 24, 36 and 48-inch griddles located at the rear of the griddle, through the back and the bottom of the griddle body. -
Page 10: Initial Start-Up
Initial Start Up During the first few hours of operation you may notice a small NOTICE amount of smoke coming from the griddle surface, and a faint odor from the smoke. This is normal for a new unit and will disappear after the first few hours of use. -
Page 11: Operation
Operation Setting the Temperature If different temperature settings across the same griddle are to be used, select one side of the griddle and run that at the lowest temperature. Adjoining sections should be set at progressively higher temperatures. Do not try to run the end sections hot and the center sections cool. -
Page 12: Cleaning
Cleaning KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER WARNING SPRAY OR HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC. MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS CAUTION MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE CLOTHING. -
Page 13: Troubleshooting
Here are some of the possible problems you may encounter and possible solutions to those problems. If the information does not assist you in correcting the problem, contact the nearest Lang service representative or Lang Manufacturing. - Page 14 Troubleshooting Cont’d Testing Possible Cause Test • No test available, operational condition Product is cooked too long Failed probe • Check probe for proper resistance Failed circuit board • Confirm that circuit board is getting correct voltage and putting out correct voltage* Failed transformer •...
-
Page 15: Parts List
Parts List May 31, 2007, Rev. B 124S-480VM Selectronic Marine Griddle PART NO. DESCRIPTION Application 2A-72500-05 LEG 4 W/BOLT DOWN ADJ 124S-480VM 2E-30303-06 SWT TOG ON-ON DPDT BLK 124S-480VM 2E-30304-22 SWTCB175-450oFW/41100-13 124S-480VM 2E-30500-02 TRM STRP 4 POLE 30A 600V 124S-480VM 2E-30500-07 TRM BLOCK 3PLELRGE 125AMP 124S-480VM... -
Page 16: Parts List
Parts List May 31, 2007, Rev. B 148S-480VM Selectronic Marine Griddle PART NO. DESCRIPTION Application 2A-72500-05 LEG 4 W/BOLT DOWN ADJ 148S-480VM 2E-30303-06 SWT TOG ON-ON DPDT BLK 148S-480VM 2E-30304-22 SWTCB175-450oFW/41100-13 148S-480VM 2E-30500-07 TRM BLOCK 3PLELRGE 125AMP 148S-480VM 2E-30501-03 TERM STRP 4 POLE W/PUSH 148S-480VM 2E-30701-04 CONTC 2POLE 30A 24VAC... - Page 17 Parts List May 31, 2007, Rev. B 172S-440VM Selectronic Marine Griddle PART NO. DESCRIPTION Application 2A-72500-05 LEG 4 W/BOLT DOWN ADJ 172S-440VM 2E-30500-03 TRM STRP 6 POLE 30A 300V 172S-440VM 2E-30500-07 TRM BLOCK 3PLELRGE 125AMP 172S-440VM 2E-30501-05 TRM STRP 6 POLE W/2PUSH 172S-440VM 2E-30701-04 CONTC 2POLE 30A 24VAC...
-
Page 20: Cruise Line Warranty
STAR MANUFACTURING 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (800) 807-9054 (314) 781-2777 Parts & Service (800) 807-9054 www.star-mfg.com...
