Page 1: Electric Griddle
THERMOSTATIC DROP-IN ELECTRIC GRIDDLE 36TDI, 48TDI, 60TDI Installation and Operation Instructions 2M-W356 Rev. D 9/07/10 IL1574 60TDI... - Page 2 REPAIRS SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY. NOTICE Using any part other than genuine Lang factory supplied parts relieves the manufacturer of all liability. Star reserves the right to change speci cations and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
-
Page 3: Table Of Contents
PROBLEMS, QUESTIONS or CONCERNS Before you proceed consult you authorized Lang service agent directory Call the Lang Technical Service & Parts Department at 1-800-438-5264. TABLE OF CONTENTS Specifications Equipment Description Unpacking Installation Prepare the Cabinet Install Griddle into the Cabinet... -
Page 4: Specifications
Model Freight Class surface Width Depth Height Width Actual Shipping 36.8” 26.8” 6.5” 30.8” 263 lbs. 410 lbs. 136TDI 933mm 679mm 165mm 781mm 120 kg 186 kg 48.8” 26.8” 6.5” 37.3” 368 lbs. 525 lbs. 148TDI Sides: 2”, Back: 2”... -
Page 5: Equipment Description
EQUIPMENT DESCRIPTION 1” Griddle Surface Gutter Grease Drawer IL1573 Power Section Temp Dial Connection Electric Drop-In Griddle The griddle dimensions are 26” (66cm) Deep, 5 3/8” (13.65cm) High, and width is dependent on model number. The griddle surface is constructed of 1” thick highly polished steel to ensure even heat throughout the griddle. -
Page 6: Unpacking
UNPACKING Receiving the Griddle Upon receipt, check for freight damage, both visible and concealed. Visible damage should be noted on the freight bill at the time of delivery and signed by the carrier’s agent. Concealed loss or damage means loss or damage, which does not become apparent until the merchandise has been unpacked. -
Page 7: Installation Prepare The Cabinet
INSTALLATION Prepare the Cabinet Cabinet base must have cross air ventilation. It does not matter if it is on the 31.750” ends or sides. If vents 26.750” are not installed, the 36.750” controls may overheat rendering the griddle 4.5” Cabinet Cut-out useless. -
Page 8: Install Griddle Into The Cabinet
INSTALLATION CONT. Install the Griddle into the Cabinet Turn the griddle over, taking care not to kink or pinch any sensor wires. Set the griddle on the table that it is to be installed in (leaving a hole big enough to slip the control panel through). Insert the control panel through the hole and out of the control opening of the cabinet. -
Page 9: Initial Start-Up Pre-Power On
INITIAL START UP Pre-Power On Before turning the griddle on verify all electrical connections and remove excess shipping grease from the griddle surface. Turning the Power On Set the main power switch, located at the far left of the control panel, to the “ON” (up) position (there are two “ON”... -
Page 10: Operation General 0
OPERATION General The suggested time and temperature chart (below) is provided as a guide for the products listed only. If different temperature settings are to be used, select one side of the griddle and operate at the lowest temperature. Adjoining sections should be set at progressively higher temperatures. Do not try to operate the end sections hot and the center sections cool. -
Page 11: Maintenance Cleaning
MAINTENANCE & CLEANING Cleaning • Always start with a cold griddle. • The stainless exterior can easily be cleaned using a good non-abrasive cleaner. • Always follow the cleaner manufacturer’s instructions when using any cleaner. • Always apply these cleaners when the griddle is cold and rub in the direction of the metal’s grain. Griddle Surface Care (non-chromium surfaces) It takes very little time and effort to keep the griddle attractive and performing at top efficiency. - Page 12 MAINTENANCE & CLEANING CONT. CALIBRATION Calibration Check Place thermometer or thermocouple in the center of griddle directly over the sensor. Set thermostat to 350°F (177°). Allow the griddle to Preheat for at least 30 minutes. Note cycle “ON” temperatures and cycle “OFF” temperatures for 3 cycles. (Red indicator light indicates when the griddle is calling for heat) After 3 cycles average the temperature.
- Page 13 • Remove the wires and check for continuity across the element * Failed element • Replace element* NOTICE: Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your Lang Authorized Service Agent Directory or call the factory at 1-800-438-5264, or WWW.STAR- MFG.COM For the service agent nearest you.
- Page 16 136TDI - 160TDI Drop-In Electric Griddle LGD Drop-In Electric Griddle LANG MANUFACTURING SK2403 10/20/2008...
-
Page 17: Parts List
PARTS LIST September 7, 2010, Rev D Model No: 136TDI, 148TDI, 160TDI Thermostatic Electric Drop-In Griddle Part Number Number Description K9-LGD-147-3 WELD PLATE 3’ ACU 136TDI K9-LGD-147-4 WELD PLATE 4’ ACU 148TDI K9-LGD-147-5 WELD PLATE 5’ ACU 160TDI K9-LGD-150-3 BOTTOM 3’... - Page 18 PARTS LIST September 7, 2010, Rev D Model No: 136TDI, 148TDI, 160TDI Thermostatic Electric Drop-In Griddle Part Number Description Number 2H-XL-424 ELEMENT PAN INSULATION 148TDI 2H-XL-424 ELEMENT PAN INSULATION 160TDI 2H-XL-424 ELEMENT PAN INSULATION 160TDI K9-XL-426 ELEMENT PAN PLATE 136TDI...
