Mode


Not inverted




Inverted
Signal levels:
 Input high signal level:
 Input low signal level:
 Current in active status (for the Easy 2 inputs):
 Current in active status (for the further Easy 2 IO inputs):
Easy 2 IO
In case of using the
which has the same operation and configuration possibility as listed here above.
When the input were activated (IN1, IN2) the IN1, IN2 titled LEDs are signing the active
(closed) status during the operation, with the proper light and colour. See LED signals part.
The device has 2 input lines (IN1, IN2). They can be configured seperately to operate as a
voltage or contact mode for the input. These settings can be setup with the jumpers besides
the IN1, IN2 input line's terminal blocks.
Connecting the relay output

One switchable output device can be connected to the relay output (OUT) of the mainboard),
according to the next figure. Connect the cable wire pair to the OUT title output line's terminal
block (by sliding the companion piece and inserting the stripped wire pair, then fixing the
screws).
Contact
NO (Normal Open)
Inactive mode: contact
opened
Active mode: contact closed
NC (Normal Closed)
Inactive mode: contact closed
Active mode: contact opened
-expander board, further 6 pcs of inputs are available (IN3..IN8),
8
Voltage
 High active
 Inactive mode: 0...1V
 Active mode: 5...24V
 Low active
 Inactive mode: 5...24V
 Active mode: 0...1V
5-24V
0-1V
0.3-3mA
1-12mA
