Related Manuals for protech PA-6222

Summary of Contents for protech PA-6222

  • Page 1 USER’S MANUAL PA-6222 12” Waterproof True Flat Touch POS Terminal Powered by Intel Celeron ® ® J1900 Quad-Core PA-6222...
  • Page 2 PA-6222 12” Waterproof True Flat Touch POS Terminal ® ® Powered by Intel Celeron J1900 Quad-Core COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Feb. 2017. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual…..............POS System Illustration…............System Specifications..............Safety Precautions…..............CHAPTER 2 SYSTEM CONFIGURATION System External I/O Port & Pin Assignment…………………… Main Board Component Locations & Jumper Settings…………. VFD Board Component Locations & Pin Assignment....MSR Board Component Locations &...

  • Page 5: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for the PA-6222. It also outlines the system specifications. Sections included:  About This Manual  POS System Illustration  System Specifications  Safety precautions Experienced users can jump to chapter 2 on page 2-1 for a quick start.

  • Page 6: About This Manual

    Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our PA-6222 Series System. The PA-6222 is an updated system designed to be comparable with the highest performance of IBM AT personal computers. The PA-6222 provides faster processing speed, greater expandability and can handle more tasks than before.

  • Page 7: Pos System Illustration

    Chapter 1 Introduction 1-2. POS SYSTEM ILLUSTRATION Small stand type Front View Rear View Top View Side View Unit: mm  Page: 3 PA-6222 SERIES USER S MANUAL...
  • Page 8 Chapter 1 Introduction Stand-less type Front View Side View Unit: mm  Page: 4 PA-6222 SERIES USER S MANUAL...

  • Page 9: System Specifications

    -50 dB -52 dB -50 dB Note: 1. Test tolerance: ± 5dB 2. AP: ASUS RT-N56U (2 x internal antenna with 3.8 dBi gain) (Distance) Angle: 0° Angle: 90° Angle: 180° Angle: 270°  Page: 5 PA-6222 SERIES USER S MANUAL...
  • Page 10 Line Out 1 x phone jack Cash Drawer 1 x RJ11(+12/24V selectable) DC-in 1 x 4pin DC Power Jack Viewing Angel 24~30˚ Serial Ports 3 x RJ45, 1 x RJ45 optional(+5V/12V selectable)  Page: 6 PA-6222 SERIES USER S MANUAL...
  • Page 11 0.15~80MHz, 3Vrms, 80% AM, 1kHz IEC 61000-4-8 PFMF 50Hz, 1A/m IEC 61000-4-11 Voltage Dips > 95% reduction for 0.5 periods  30% reduction for 25 periods  Voltage Interruptions > 95% reduction for 250 periods  Page: 7 PA-6222 SERIES USER S MANUAL...
  • Page 12 MSR & i-Button JIS-I or II, ISO Track1+2+3 Fingerprint 8-bit grayscale reader Display 8” LCD or 10.4” LCD  Customer Display VFD, 20 columns and 2 lines, each column is 5 x 7 dots  Page: 8 PA-6222 SERIES USER S MANUAL...

  • Page 13: Safety Precautions

    Avoid exposure to sunlight for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use the PA-6222 when it has been left outdoors in a cold winter day.

  • Page 14: Chapter 2 System Configuration

     External I/O Port Pin Assignment  How to Set Jumpers  Component Locations & Jumper Settings - Mainboard - VFD Board (peripheral device) - MSR Board (peripheral device)  Secondary Cash Drawer Port ’ Page: 10 PA-6222 SERIES USER S MANUAL...

  • Page 15: System External I/O Port & Pin Assignment

    Chapter 2 System Configuration 2-1. SYSTEM EXTERNAL I/O PORT & PIN ASSIGNMENT Rear I/O Side I/O Power USB4 button ’ Page: 11 PA-6222 SERIES USER S MANUAL...
  • Page 16 +3.3V DC-IN Port DC-IN: DC Power-In Port (rear IO) ASSIGNMENT ASSIGNMENT +24V +24V DC-IN VGA Port VGA: VGA Port, D-Sub 15-pin (rear IO) ASSIGNMENT ASSIGNMENT GREEN BLUE DDCA DATA HSYNC VSYNC DDCA CLK ’ Page:12 PA-6222 SERIES USER S MANUAL...
  • Page 17 1A) USB Port USB0, USB1, USB2, USB3, USB4: USB Port Type A Ports USB0~3: Real I/O  USB4: Side IO  ASSIGNMENT ASSIGNMENT +5V(Maximum USB0/ current: 0.5A) USB1/ USB2/ USB4/ USB3 ’ Page: 13 PA-6222 SERIES USER S MANUAL...
  • Page 18 10/100Mbps LAN Speed Indicator Orange Color on Giga LAN Speed Indicator No LAN switch/ hub connected. Display Power Port (Optional) DIS PWR: DV12 Power Supply of 2 Display ASSIGNMENT DIS PWR VCC12 VCC12 ’ Page:14 PA-6222 SERIES USER S MANUAL...
  • Page 19 +12V/+24V (Max. current: 1A) Drawer Open Drawer Sense DRW1 Open Close PB-6822RA, RB Write To Write To 700h 588h 000h 588h DRW1 Write To Write To PB-6822RC SIO LDN SIO LDN 06h’s 90h 06h’s 90h ’ Page: 15 PA-6222 SERIES USER S MANUAL...

  • Page 20: Mainboard Component Locations & Jumper Settings

    JPWR_4P1 DIMM1 SATA2 JPWR_4P2 TOUCH1 USB6 JI_BUTTON1 Battery JP19 JP_VDD1 SPK1 JP32 SLOT1 JP15 SW1_3 JP14 JINV4 USB1 16 18 15 17 LED1_3 JINV1 USB7 J3 LVDS1 COM4_2 LED1_1 PB-6822 Mainboard Component Locations ’ Page:16 PA-6222 SERIES USER S MANUAL...
  • Page 21 PIN1 & PIN2 to create one setting and shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ’ Page: 17 PA-6222 SERIES USER S MANUAL...
  • Page 22 Chapter 2 System Configuration Jumper diagrams Jumper settings ’ Page:18 PA-6222 SERIES USER S MANUAL...
  • Page 23 3. Voltage of COM port is adjustable by BIOS or jumpers. Either way cannot be applied simultaneously in case of system error, component damage or serious boot failure. PS: COM4 is optional ’ Page: 19 PA-6222 SERIES USER S MANUAL...
  • Page 24 JP20, JP21, JP22: i-Button Function Connectors SELECTION JUMPER SETTING JUMPER ILLUSTRATION COM 3 JP20/JP21/JP22/ i-Button* JP20/JP21/JP22/ Note: Manufacturing Default is COM3. *COM3 & COM3-1 will not function when jumpers JP20, JP21 & JP22 are set as “i-Button.” ’ Page:20 PA-6222 SERIES USER S MANUAL...
  • Page 25 2. JP29 is enabled when Cash drawer is disabled on BIOS. 3. Voltage of cash drawer port is adjustable by BIOS or jumpers. Either way cannot be applied simultaneously in case of system error, component damage or serious boot failure. ’ Page: 21 PA-6222 SERIES USER S MANUAL...
  • Page 26 5V (Maximum current: 0.5A) USB1/ USB2/ USB7/ Note: USB1 would be used when jumpers JP14 & JP15 are set as 1-2 (short) connected. USB6 LED Connector LED1_1, LED1_3: Power indication LED connector ASSIGNMENT LED1_1/ PWR_LED LED1_3/ ’ Page:22 PA-6222 SERIES USER S MANUAL...
  • Page 27 DC5V_PWR1: DC 5Voltage Provider Connector ASSIGNMENT DC5V_PWR1 Power for Thermal Printer Connector PRT_PWR1: Power for Thermal Printer Connector ASSIGNMENT VCC24SB PRT_PWR1 VCC24SB External Speaker Connector SPK1, SPK2: External speaker connector ASSIGNMENT SPK_GND SPK1/ SPK_OUT SPK2/ ’ Page: 23 PA-6222 SERIES USER S MANUAL...
  • Page 28 It applied to the panel driver on M/B without driver built-in JP12 3-5, 4-6 Control by It applied to the panel with built-in driver inside JP12 Note: Manufacturing Default is Control by PWM. ’ Page:24 PA-6222 SERIES USER S MANUAL...
  • Page 29 Note: Manufacturing Default is 1024 x 768 (24bit). LVDS Connector LVDS1: LVDS Connector ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS_CLKA_D+ VDS_CLKA_D- LVDS1 LVDS_A2_D+ LVDS_A2_D- LVDS_B2_D- LVDS_B2_D+ LVDS_A1_D+ LVDS_A1_D- LVDS_B1_D- LVDS_B1_D+ LVDS_A0_D+ LVDS_B3_D+ LVDS_A0_D- LVDS_B3_D- LVDS_A3_D+ LVDS_B0_D+ LVDS_A3_D- LVDS_B0_D- LVDS_VCC LVDS_VCC ’ Page: 25 PA-6222 SERIES USER S MANUAL...
  • Page 30 Note: 1. Manufacturing Default is USB Interface. 2. The COM2 & COM2-1 connector will not function when JP38 & JP39 are set as 1-2 connected. 3. USB1 connector when JP14 & JP15 are set as 1-2 connected. ’ Page:26 PA-6222 SERIES USER S MANUAL...
  • Page 31 After five to six seconds, set the jumper back to “Normal” and power-on the computer. MSR/Card Reader Connector PS/2_1, PS/2_2: MSR/Card reader connectors ASSIGNMENT KB_CLK (Output) PS/2_1 KB_CLK_C (Input) KB_DATA_C (Input) KB_DATA (Output) PS/2_2 ’ Page: 27 PA-6222 SERIES USER S MANUAL...
  • Page 32 ASSIGNMENT SATA1/ SATA2/ Note: SATA1 only supports the optional RAID function on board. JPWR_4P1, JPWR_4P2: Serial ATA power connectors ASSIGNMENT JPWR_4P1/ JPWR_4P2/ VCC12 Note: JPWR_4P1 only supports the optional RAID function on board. ’ Page:28 PA-6222 SERIES USER S MANUAL...
  • Page 33 Chapter 2 System Configuration Printer Connector LPT1 LPT1: Printer connector ASSIGNMENT ASSIGNMENT STBJ ALFJ PDR0 ERRJ PDR1 PAR_INITJ PDR2 SLCTINJ PDR3 PDR4 PDR5 PDR6 PDR7 ACKJ BUSY SLCTJ ’ Page: 29 PA-6222 SERIES USER S MANUAL...
  • Page 34 +3.3V +1.5V SLOT1 Reserved SMB_CLK Reserved PETn2 +1.5V SMB_DATA CLKREQ# PETp2 Reserved Reserved REFCLK1- Reserved REFCLK1+ +3.3V Reserved +3.3V Reserved Reserved Reserved Reserved Reserved Reserved Reserved PERST# +1.5V PERn2 +3.3SB PERp2 Reserved +3.3V ’ Page:30 PA-6222 SERIES USER S MANUAL...

  • Page 35: Vfd Board Component Locations & Pin Assignment

    Chapter 2 System Configuration 2-3. VFD BOARD COMPONENT LOCATIONS & PIN ASSIGNMENT VFD Board: MB-4103, LD720 JP12V MB-4103 & LD720 VFD Board Component Locations ’ Page: 31 PA-6222 SERIES USER S MANUAL...
  • Page 36 Chapter 2 System Configuration Power Switch Selection JP12V: Power Switch Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION JP12V JP12V Note: Manufacturing Default is ON. RS-232 Serial Interface Connector CN1: RS-232 serial interface wafer ASSIGNMENT ASSIGNMENT +12V/+5V ’ Page:32 PA-6222 SERIES USER S MANUAL...

  • Page 37: Msr Board Component Locations & Pin Assignment

    2-4. MSR BOARD COMPONENT LOCATIONS & PIN ASSIGNMENT ID TECH ID-TECH MSR Board Component Locations Main Connector ASSIGNMENT ASSIGNMENT Chassis Ground K-CLK (Computer connections) P-CLK K-DATA (Keyboard connections) (Computer connections) P-DATA (Keyboard connections) +5V Vcc ’ Page: 33 PA-6222 SERIES USER S MANUAL...
  • Page 38 I_BUTTON1 MB-3012 MSR Board Component Locations Information Button Reader I_BUTTON1: Information button reader ASSIGNMENT I_B1 I_BUTTON1 Output Connector IO1: Output wafer ASSIGNMENT ASSIGNMENT CLK_KB RX_MSR CLK_PC TX_MSR DATA_KB DATA_PC USB_D+_R USB_D-_R CHASSIS GND ’ Page:34 PA-6222 SERIES USER S MANUAL...

  • Page 39: Secondary Cash Drawer

    Set the pin-header jumper JP37 as 1-2 connected if necessary. JP37: DRW1-2 control connector SELECTIO JUMPER SETTING JUMPER ILLUSTRATION DRW1-2 Open Note: Manufacturing Default is GND. ’ Page: 35 PA-6222 SERIES USER S MANUAL...
  • Page 40 Write 700h 588h 000h 588h PB-6822RC Write Write SIO LDN06h’s 90h SIO LDN 06h’s 90h DRW1-2 OPEN CLOSE PB-6822RA, RB Write Write PB-6822RC Write Write SIO LDN 06h’s 90h SIO LDN 06h’s 90h ’ Page:36 PA-6222 SERIES USER S MANUAL...

  • Page 41: Chapter 3 Software

    - Touchsreen Driver Utility - For Intel Trusted Execution Engine Interface Embedded Peripheral Device  - VFD - MSR  BIOS Operation  - Setup - Watchdog Timer Configuration - Update Procedure - System Resource Map  Page:37 PA-6222 SERIES USER S MANUAL...

  • Page 42: Driver

    Chapter 3 Software 3-1. DRIVER 3-1-1. Introduction Enclosed with the PA-6222 Series package is our driver utilities, which comes in a DVD-ROM format. 3-1-1-1 . API Package Folder Refer to the "3-3 API" for the details. +--->\DEMO PROJECT\ +--->\ProxAPI standard\ +--->\Document\...
  • Page 43 10 series, and it should be installed right after the OS installation. Please follow the steps below: Connect the USB CD-ROM device to PA-6222 and insert the driver disk. Enter the “Main Chip” folder where the Chipset driver is located (depending on your OS platform).

  • Page 44: Vga Driver Utility

    Chapter 3 Software 3-1-3. VGA Driver Utility The VGA interface embedded with PA-6222 can support a wide range of display types. You can have dual displays via CRT & LVDS interfaces work simultaneously. 3-1-3-1. Installation of VGA Driver To install the Graphics driver, follow the steps below: Connect the USB-CD ROM device to PA-6222 and insert the driver disk.

  • Page 45: Sound Driver Utility

    OS platform). Click Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once the installation is completed, shut down the system and restart PA-6222 for the changes to take effect. 3-1-6. Touchscreen Driver Utility The touchscreen driver utility can only be installed on Windows POSReady 7 &...
  • Page 46 Click Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once the installation is completed, shut down the system and restart PA-6222 for the changes to take effect. 3-1-8. RFID Module Driver Utility (Optional) The RFID driver utility can only be installed on Windows POSReady7 & Windows 8 &...
  • Page 47 Enter the “Device\WIFI module” folder where the wireless driver is located. Click exe file for driver installation. Follow the on-screen instructions to complete the installation. Once the installation is completed, shut down the system and restart PA-6222 for the changes to take effect. 3-1-10. For Intel Trusted Execution Engine Interface 3-1-10-1.

  • Page 48: Embedded Peripheral Devices

    Port COM1 Stop OPOS VFD Service Object and Method Relations Method Status of support Notes Open ○ Close ○ ClaimDevice ○ ReleaseDevice ○ Enable ○ Disable ○ DisplayText ○ DisplayTextAt ○ ClearText ○  Page:44 PA-6222 SERIES USER S MANUAL...
  • Page 49  This setup also installs the Prox-PMP4000 program.  Follow the wizard instructions to complete the installation. Launching Program Below steps guide you to load the Prox-PMP4000 program.  Click LineDisplay folder from the path Start/Programs/Protech OPOS.  Click Prox-PMP4000 to launch the program.  Page:45...
  • Page 50 Default Value Note BaudRate String 9600 UART Baud Rate (default) BitLength String UART Data Bit (default) Parity String UART Parity Bit (default) Port String COM1 UART Port (default) Stop String UART Stop Bit (default)  Page:46 PA-6222 SERIES USER S MANUAL...
  • Page 51 Read only Not Applicable Properties specific long CapReverse Read only Not Applicable Properties specific bool CapVMarquee Read only Not Applicable Properties specific long BlinkRate Not Applicable Properties specific long DeviceWindows Read only Not Applicable  Page:47 PA-6222 SERIES USER S MANUAL...
  • Page 52 SetDescriptor Not Applicable Methods specific ClearDescriptors Not Applicable Methods specific CreateWindow Not Applicable Methods specific DestroyWindow Not Applicable Methods specific RefreshWindow Not Applicable) Methods specific ReadCharacterAtCursor Not Applicable Methods specific DefineGlyph Not Applicable  Page:48 PA-6222 SERIES USER S MANUAL...
  • Page 53 Mutability OPOS VFD .SO Type Version Events common DataEvent Not Applicable Events common DirectIOEvent Not Applicable Events common ErrorEvent Not Applicable Events common OutputComplete Not Applicable Event Events common StatusUpdate Not Applicable Event  Page:49 PA-6222 SERIES USER S MANUAL...
  • Page 54  This setup also installs the Prox-PMP3000 program.  Follow the wizard instructions to complete the installation. Launching Program Below steps guide you load the Prox-PMP3000 program.  Click MSR folder from the path Start/Programs/Protech OPOS.  Click Prox-PMP3000 to launch the program.  Page:50...
  • Page 55 Configuration of Prox-PMP3000 program a.) Main screen & Control tab items: Button/Item Description (dropdown list) To set COM port number (only for USRT/USB interface). AutoDisable (check box) Set auto-disable FreeseEvents (check box) Set freeze events  Page:51 PA-6222 SERIES USER S MANUAL...
  • Page 56 ParseDecodeData Set parse decode data properties TransmitSentinels Set transmit-sentinels properties ErrorReporting Type Card, track TracksToRead Track1, track2, track3, tracks12, tracks13, tracks14, tracks23, tracks24, tracks34, tracks123, tracks124, tracks134, tracks234, tracks1234 (Tracks4 is not applicable).  Page:52 PA-6222 SERIES USER S MANUAL...
  • Page 57 (Row) Display data of all tracks (Track4 is not applicable). e.) Parsed Data tab items Button/Item Description Parsed Data Display special properties. MB301X type (RS232/PS2) Key Name Type Default Value Note default string PMP3000 OPOS S.O Link  Page:53 PA-6222 SERIES USER S MANUAL...
  • Page 58 Properties specific string Track3Data Read only Supported Properties specific string Track4Data Read only Not Applicable Properties specific string AccountNumber Read only Supported Properties specific string ExpirationDate Read only Supported Properties specific string Title Read only Supported  Page:54 PA-6222 SERIES USER S MANUAL...
  • Page 59 ClearOutput Not Applicable Methods common DirectIO Not Applicable Events common DataEvent Supported Events common DirectIOEvent Not Applicable Events common ErrorEvent Not Applicable Events common OutputCompleteEvent Not Applicable Events common StatusUpdateEvent Not Applicable  Page:55 PA-6222 SERIES USER S MANUAL...
  • Page 60 Devive Name for CO open FileName (NULL) (reserved) HardwareProvider (reserved) Model MJR243 Device model name Parity None Parity for the communication port Port COM4 Comport Protocol Hardware Communication Control Baudrate 19200 RS232 baudrate  Page:56 PA-6222 SERIES USER S MANUAL...
  • Page 61 ○ Read only MiddleInitial ○ Read Only ParseDecodeData ○ ServiceCode ○ Read Only Suffix ○ Read Only Surname ○ Read Only Title ○ Read Only Track1Data ○ Read Only Track1DiscretionaryData ○ Read Only  Page:57 PA-6222 SERIES USER S MANUAL...
  • Page 62 Chapter 3 Software Method Status of support by Notes the driver Track2Data ○ Read Only Track2DiscretionaryData ○ Read Only Track3Data ○ Read Only TracksToRead ○ TransmitSentinels ○  Page:58 PA-6222 SERIES USER S MANUAL...
  • Page 63  Follow the wizard instructions to complete the installation. Launching Program Below steps guide you to load the OPOS MSR Register program.  Click OPOS folder from the path Start/Programs/GIGA ‐ TMS.  Click OPOS MSR Register to launch the program.  Page:59 PA-6222 SERIES USER S MANUAL...
  • Page 64 Step 1: Select an item in Service Object List box (left pane). Make sure the correct item is selected. Step 2: Click Reg button Step 3: In the OPOS MSR Setting screen, enter the device name and click OK.  Page:60 PA-6222 SERIES USER S MANUAL...
  • Page 65 Chapter 3 Software c.) Example 1. MAGTEK USB HID d.) Example 2. PROMAG MSR/MJR PART‐ NO, Keyboard mode.  Page:61 PA-6222 SERIES USER S MANUAL...
  • Page 66 Devive Name for CO open FileName string (NULL) (reserved) HardwareProvider string (reserved) Model string MJR243 Device model name Parity for the communication Parity string None port Port string COM4 Comport Number Protocol string Hardware Communication Control  Page:62 PA-6222 SERIES USER S MANUAL...
  • Page 67 Supported Properties specific bool CapJISOne Read only Not Applicable Properties specific bool CapJISTwo Read only Not Applicable Properties specific bool CapTransmit Read only Supported Sentinels Properties specific long CapWriteTracks Read only Not Applicable  Page:63 PA-6222 SERIES USER S MANUAL...
  • Page 68 ClearInput Supported Methods common ClearInput Supported Properties Methods common ClearOutput Not Applicable Methods common DirectIO Not Applicable Methods common Compare Not Applicable FirmwareVersion Methods common ResetStatistics Not Applicable Methods common RetrieveStatistics Not Applicable  Page:64 PA-6222 SERIES USER S MANUAL...
  • Page 69 UpdateFirmware Not Applicable Methods common UpdateStatistics Not Applicable Events common DataEvent Supported Events common DirectIOEvent Not Applicable Events common ErrorEvent Not Applicable Events common OutputCompleteEvent Not Applicable Events common StatusUpdateEvent Not Applicable  Page:65 PA-6222 SERIES USER S MANUAL...
  • Page 70 MSR Register program. Launching Program Below steps guide you to load the OPOS MSR Tester program.  Click OPOS folder from the path Start\Programs\GIGA ‐ TMS.  Click OPOS MSR Tester to launch the program.  Page:66 PA-6222 SERIES USER S MANUAL...
  • Page 71 To start using OPOS driver to get track data, follow the steps below. Step 1: Entering the Device Name. Step 2: Clicking Open button. Step 3: Swiping card to get track data.  Page:67 PA-6222 SERIES USER S MANUAL...
  • Page 72 Chapter 3 Software c.) Example 1. MAGTEK USB HID. d.) Example 2. PROMAG MSR/MJR PART‐ NO, Keyboard mode  Page:68 PA-6222 SERIES USER S MANUAL...
  • Page 73 Chapter 3 Software e.) Example 3. PROMAG MSR PART‐ NO, HID mode  Page:69 PA-6222 SERIES USER S MANUAL...

  • Page 74: Api

    XML file for each model Name*\Initial.xml Version.ini Version information Sample Program Directory Contents / File Name Description DEMO PROJECT\GPIO Sample C# VB6 VB.net Source Code DEMO Code PROJECT\ DEMO PROJECT\Digital C# VB6 VB.net Source Code Sample Code  Page:70 PA-6222 SERIES USER S MANUAL...
  • Page 75 End if ‘========================================= Receive_Status2 = CashDrawerOpen(&H2) If Receive_Status2 = true then Text2.text = “cash drawer2 open” ‘enter text into textbox. Else Text2.text = “cash drawer2 close”‘enter text into textbox. End if ‘========================================= End sub  Page:71 PA-6222 SERIES USER S MANUAL...
  • Page 76 Open cash drawer: CashDrawerOpen(1) Open cash drawer1 CashDrawerOpen(2) Open cash drawer2 Check cash drawer status: Dim receive_status as Boolean Check cash drawer1 status Receive_Status = CashDrawerOpen(&H1) Check cash drawer2 status Receive_Status = CashDrawerOpen(&H2)  Page:72 PA-6222 SERIES USER S MANUAL...
  • Page 77 Open cash drawer1 PortAccess.CashDrawerOpen(0x01); //check cash drawer1 status Open cash drawer2 PortAccess.CashDrawerOpen(0x02); //check cash drawer2 status Bool bstatus; bstatus = PortAccess.GetCashDrawerStatus(0x01); bstatus = PortAccess.GetCashDrawerStatus(0x02); //Before get cash drawer status, need to initial cash drawer first  Page:73 PA-6222 SERIES USER S MANUAL...
  • Page 78 As Boolean VB 6 extern function: Declare Function CashDrawerOpen Lib "CashDrawer.dll" (ByVal num_drawer As Integer) As Boolean Declare Function GetCashDrawerStatus Lib "CashDrawer.dll" (ByVal num_drawer As Integer) As Boolean Note: VB.net short = integer VB6  Page:74 PA-6222 SERIES USER S MANUAL...

  • Page 79: Cash Drawer

    OPEN (button) Tap to open the cash drawer. Cash Drawer Status Cash drawer status will be displayed after OPEN is tapped.  Drawer is closed as shown:  Drawer is open as shown:  Page:75 PA-6222 SERIES USER S MANUAL...
  • Page 80 The API program-related sample programs, developed in VB.Net and C#, are provided for easy use of the API Package. Refer to the main API functions listed as below. API Function CashDrawerOpen multilangXML.dll CashDrawer.dll Cash Drawer GetCashDrawerStatus  Page:76 PA-6222 SERIES USER S MANUAL...
  • Page 81 True (1) on success, False (0) on failure Example: Short data; data= GetCashDrawerStatus(0x01); // Get the Cash Drawer1 status if (data) MsgBox(“open1”); // Cash Drawer1 status “Open” Else MsgBox(“close1”); // Cash Drawer1 status “Close” Endif  Page:77 PA-6222 SERIES USER S MANUAL...

  • Page 82: Bios Operation

    3-4. BIOS Operation 3-4-1. Introduction The board PA-6222 uses an AMI Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS Setup program, Power-on Self-Test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 83 The BIOS Setup program can be used to view and change the BIOS settings for the computer. The BIOS Setup program is accessed by pressing the <Del> or <ESC> key after the POST memory test begins and before the operating system boot begins. The settings are shown below.  Page:79 PA-6222 SERIES USER S MANUAL...

  • Page 84: Entering Setup

    Setup program. In a moment, the main menu of the Aptio Setup Utility will appear on the screen:  Page:80 PA-6222 SERIES USER S MANUAL...
  • Page 85 You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen.  Page:81 PA-6222 SERIES USER S MANUAL...
  • Page 86 No changeable options Displays the current TXE Version Version System English BIOS Setup language. Language System Date Month, day, year Specifies the current date. System Time Hour, minute, second Specifies the current time.  Page:82 PA-6222 SERIES USER S MANUAL...
  • Page 87 SATA Configuration Parameters. Voltage Adjust Sub-Menu Voltage Adjust settings. Configuration CSM Configuration Sub-Menu Configure Option ROM execution, boot options filters, etc. USB Configuration Sub-Menu USB Configuration Parameters. SIO Configuration Sub-Menu SIO Configuration Parameters.  Page:83 PA-6222 SERIES USER S MANUAL...
  • Page 88  Suspend Disabled disables ACPI RAM) sleep feature.  S3 allows the platform to enter suspend to RAM mode. Lock Legacy - Disabled Enables or Disables Lock of Legacy Resources. - Enabled Resources.  Page:84 PA-6222 SERIES USER S MANUAL...
  • Page 89 Displays voltage level of the +VSB5 in supply. VCC5 No changeable options Displays voltage level of the + VCC5 in supply. VCC12 No changeable options Displays voltage level of the + VCC12 in supply.  Page:85 PA-6222 SERIES USER S MANUAL...
  • Page 90 Enable/ Disable Watch dog timer. WatchDog -Disable Watchdog Select seconds or minutes timer unit -60s Count for Multiple options Sets the desired value (seconds) for Timer ranging from 1 to 255 watchdog timer. (Seconds)  Page:86 PA-6222 SERIES USER S MANUAL...
  • Page 91 - Enabled CPUID functions. Set disable for WinXP. Intel - Disabled When enabled, a VMM can utilize the Virtualization additional hardware capabilities - Enabled provided by Vanderpool Technology Technology(VT).  Page:87 PA-6222 SERIES USER S MANUAL...
  • Page 92 Displays size of L1 Data Cache L1 Code Cache No changeable options Displays size of L1 Code Cache L2 Cache No changeable options Displays size of L2 Cache. L3 Cache No changeable options Displays size of L3 Cache.  Page:88 PA-6222 SERIES USER S MANUAL...
  • Page 93 Chapter 3 Software 3-4-4-5. PPM Configuration PPM Configuration screen BIOS Options Description/Purpose Setting EIST -Disabled Enable/Disable Intel SpeedStep. -Enabled  Page:89 PA-6222 SERIES USER S MANUAL...
  • Page 94 Enable or disable SATA port 1 Device Port 1 - Enabled SATA Port1 - Disabled Enable or disable SATA port 1 Device HotPlug HotPlug - Enabled SATA Port 0 [drive] Displays the drive installed on this SATA port  Page:90 PA-6222 SERIES USER S MANUAL...
  • Page 95 Chapter 3 Software BIOS Options Description/Purpose Setting 0. Shows [Empty] if no drive is installed. SATA Port 1 [drive] Displays the drive installed on this SATA port 1. Shows [Empty] if no drive is installed.  Page:91 PA-6222 SERIES USER S MANUAL...
  • Page 96 Select COM3 Port voltage. Select - RI -12V COM4 Voltage - Disabled Select COM4 Port voltage. Select - RI -12V Cash drawer - Cash drawer 12V Select Cash drawer voltage. - Cash drawer 24V  Page:92 PA-6222 SERIES USER S MANUAL...
  • Page 97  Always: Do not allow disabling GA20; this option is useful when any RT code is executed above 1MB. Option ROM - Force BIOS Set display mode for Option ROM Messages messages. - Keep Current  Page:93 PA-6222 SERIES USER S MANUAL...
  • Page 98 - Legacy only - Legacy first - UEFI first Other PCI - UEFI first Select launch method for other PCI devices, such as NIC, mass storage or devices - Legacy only video card.  Page:94 PA-6222 SERIES USER S MANUAL...
  • Page 99 Storage Driver driver support. - Enabled Support USB transfer 1/5/10/20 sec The time-out value for Control, Bulk, time-out and Interrupt transfers. Device reset 10/20/30/40 sec USB mass storage device Start Unit time-out command time-out.  Page:95 PA-6222 SERIES USER S MANUAL...
  • Page 100 0 to 40 second increments seconds Mass Storage - Auto Display the device name and choose Devices: the device emulation type. - Floppy - Force FDD - Hard Disk - CD-ROM  Page:96 PA-6222 SERIES USER S MANUAL...
  • Page 101 Set Parameters for COM2 Serial Port 2 [*Active*] Sub-menu Set Parameters for COM3 Serial Port 3 [*Active*] Sub-menu Set Parameters for COM4 Serial Port 4 [*Active*] Sub-menu Set Parameters for LPT port. Parallel Port  Page:97 PA-6222 SERIES USER S MANUAL...
  • Page 102 - Use Automatic Settings Select IRQ and I/O resource - IO=3F8h; IRQ=4 DMA for the serial - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA port 1. - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA  Page:98 PA-6222 SERIES USER S MANUAL...
  • Page 103 - Use Automatic Settings Select IRQ and I/O resource - IO=2F8h; IRQ=3 DMA for the serial - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA port 2 - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2E8h; IRQ=3,4,5,6,7,10,11,12 DMA  Page:99 PA-6222 SERIES USER S MANUAL...
  • Page 104 - IO=3E8h; IRQ=7 DMA I/O resource for the serial - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA port 3 - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12 DMA  Page:100 PA-6222 SERIES USER S MANUAL...
  • Page 105 I/O resource for - IO=2E8h; IRQ=7 DMA the serial port 4 - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12 DMA  Page:101 PA-6222 SERIES USER S MANUAL...
  • Page 106 Displays current settings of setting the printer port. Current Possible: - Auto Select IRQ and I/O resource for the printer - IO=378h; IRQ=5 port. - IO=378h; IRQ=5,6,7,9,10,11,12 - IO=278h; IRQ=5,6,7,9,10,11,12 - IO=3BCh; IRQ=5,6,7,9,10,11,12  Page:102 PA-6222 SERIES USER S MANUAL...
  • Page 107 - ECP and EPP 1.7 Mode printers.  EPP is Enhanced Parallel Port mode, a high-speed bi-directional mode for non-printer peripherals.  ECP is Enhanced Capability Port mode, a high-speed bi-directional mode for printers and scanners.  Page:103 PA-6222 SERIES USER S MANUAL...
  • Page 108 Chapter 3 Software 3-4-5. Chipset Chipset screen BIOS Options Description/Purpose Setting North Bridge Sub-menu Sets Parameter for Panther Point (North Bridge) configuration. South Bridge Sub-menu Sets Parameter for Ivy Bridge (South Bridge) configuration.  Page:104 PA-6222 SERIES USER S MANUAL...
  • Page 109 North Bridge screen BIOS Options Description/Purpose Setting Intel IGD Sub-menu Configure Graphic Settings. Configuration Memory No changeable options Displays the DRAM information on Information platform. Total Memory No changeable options Displays the DRAM size  Page:105 PA-6222 SERIES USER S MANUAL...
  • Page 110 - Enabled DVMT Pre- - 32M Select DVMT 5.0 Pre-Allocated Allocated (Fixed) Graphics Memory size used - 64M by the Internal Graphics Device. - 96M - 128M - 256M - 512M  Page:106 PA-6222 SERIES USER S MANUAL...
  • Page 111  Power On makes system power on after restores AC power to the board.  Last State brings system back to the last power state before AC remove.  Page:107 PA-6222 SERIES USER S MANUAL...
  • Page 112 Enabled or Disabled USB port 1 - Enabled USB Port 2 - Disabled Enabled or Disabled USB port 2 - Enabled USB Port 3 - Disabled Enabled or Disabled USB port 3 - Enabled  Page:108 PA-6222 SERIES USER S MANUAL...
  • Page 113 Selection PCI Express port 2 Speed - Gen1 - Gen2 PCI Express - Disabled Enabled or Disabled PCI Express port 3 Port 3 - Enabled - Auto speed Selection PCI Express port 3 Speed - Gen1 - Gen2  Page:109 PA-6222 SERIES USER S MANUAL...
  • Page 114 Description/Purpose Setting Administrator Password can be 3-20 Specifies the administrator password. alphanumeric Password characters. User Password Password can be 3-20 Specifies the user password. alphanumeric characters. HDD Security Sub-menu Set HDD password. Configuration:  Page:110 PA-6222 SERIES USER S MANUAL...
  • Page 115 - Enabled Boot Option - [Drive(s)] Allows setting boot option listed in #1~#n Hard Drive BBS Priorities. - Disabled Hard Drive Sub-Menu Allow user to select boot order of BBS Priorities available drive(s)  Page:111 PA-6222 SERIES USER S MANUAL...
  • Page 116 Chapter 3 Software 3-4-7-1. Hard Drive BBS Priorities Hard drive BBS priorities screen BIOS Options Description/Purpose Setting Boot Option #1 - [Drive(s)] Change the boot order of available - #n drive(s). - Disabled  Page:112 PA-6222 SERIES USER S MANUAL...
  • Page 117 Resets without saving any changes Changes and made in BIOS settings. Reset Restore No changeable options Loads the optimized defaults for BIOS Defaults settings. Boot Override - [Drive(s)] Forces to boot from selected [drive(s)].  Page:113 PA-6222 SERIES USER S MANUAL...

  • Page 118: Watchdog Timer Configuration

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode.  Page:114 PA-6222 SERIES USER S MANUAL...
  • Page 119 ;------ Select Logical Device 7 of watchdog timer ------------------------------------------- ;------ Enable Watch dog feature -------------------------------------------- 030h ;------ Enable Watch PME-------------------------------------------- 0FAh ;------ Set second as counting unit -------------------------------------------------------------- 0f5h ;------ Set timeout interval as 30seconds and start counting --------------------------------- 0f6h  Page:115 PA-6222 SERIES USER S MANUAL...
  • Page 120 Chapter 3 Software ;------ Exit the extended function mode -------------------------------------------------------- 0aah  Page:116 PA-6222 SERIES USER S MANUAL...

  • Page 121: Bios Update Instructions

    Select [Boot] menu as the picture shows below. Select [Hard Drive BBS Priorities], set the USB bootable device as the 1 boot device. Press <F4> key to save configuration and exit the BIOS setup menu.  Page:117 PA-6222 SERIES USER S MANUAL...
  • Page 122 The recommended options for BIOS ROM update consist of following parameters: program main BIOS image /B: program Boot Block /N: program NVRAM /X: don’t check ROM ID  Page:118 PA-6222 SERIES USER S MANUAL...
  • Page 123 You can restart the system and boot up with new BIOS now Update is complete after restart Verify during the following boot that BIOS version displayed at the initialization screen has changed.  Page:119 PA-6222 SERIES USER S MANUAL...
  • Page 124 Chapter 3 Software  Page:120 PA-6222 SERIES USER S MANUAL...

  • Page 125: System Resource Map

    Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:121 PA-6222 SERIES USER S MANUAL...
  • Page 126 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:122 PA-6222 SERIES USER S MANUAL...
  • Page 127 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:123 PA-6222 SERIES USER S MANUAL...
  • Page 128 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:124 PA-6222 SERIES USER S MANUAL...
  • Page 129 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:125 PA-6222 SERIES USER S MANUAL...
  • Page 130 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:126 PA-6222 SERIES USER S MANUAL...
  • Page 131 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:127 PA-6222 SERIES USER S MANUAL...
  • Page 132 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:128 PA-6222 SERIES USER S MANUAL...
  • Page 133 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:129 PA-6222 SERIES USER S MANUAL...
  • Page 134 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System  Page:130 PA-6222 SERIES USER S MANUAL...
  • Page 135 USB 3.0 eXtensible Host Controller - 0100 (Microsoft) ® 4294967293 Intel Trusted Execution Engine Interface 4294967294 Realtek PCIe GBE Family Controller 3-7-2. DMA Channels Map TIMER ASSIGNMENT CHANNEL Channel 4 Direct memory access controller  Page:131 PA-6222 SERIES USER S MANUAL...
  • Page 136 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000002E8-0x000002EF Communications Port (COM4) 0x000002F8-0x000002FF Communications Port (COM2)  Page:132 PA-6222 SERIES USER S MANUAL...
  • Page 137 N- and J-series AHCI - 0F23 ® ® 0x0000F070-0x0000F077 Intel Pentium processor N- and J-series / ® ® Intel Celeron processor N- and J-series AHCI - 0F23 ® 0x0000F080-0x0000F087 Intel HD Graphics  Page:133 PA-6222 SERIES USER S MANUAL...
  • Page 138 N- and J-series AHCI - 0F23 ® 0xE00000D0-0xE00000DB Intel Sideband Fabric Device ® 0xFF000000-0xFFFFFFFF Intel 82802 Firmware Hub Device 0xA0000-0xBFFFF PCI Express Root Complex ® 0xA0000-0xBFFFF Intel HD Graphics 0xC0000-0xDFFFF PCI Express Root Complex  Page:134 PA-6222 SERIES USER S MANUAL...
  • Page 139 Chapter 3 Software MEMORY MAP ASSIGNMENT 0xE0000-0xFFFFF PCI Express Root Complex  Page:135 PA-6222 SERIES USER S MANUAL...

  • Page 140: Chapter 4 System Diagrams

    CHAPTER SYSTEM DIAGRAMS This appendix contains exploded diagrams and part numbers of the PA- 6222 system. Sections included: Exploded Diagram for Panel PC   Cable Cover  Storage  Back Cover  Touchscreen & LCD Panel  Inside Case Exploded Diagram for Peripheral Devices ...

  • Page 141: Exploded Diagram For Cable Cover

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR CABLE COVER  Page: 138 PA-6222 SERIES USER S MANUAL...

  • Page 142: Exploded Diagram For Storage

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR STORAGE  Page: 139 PA-6222 SERIES USER S MANUAL...

  • Page 143: Exploded Diagram For Back Cover

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR BACK COVER  Page: 140 PA-6222 SERIES USER S MANUAL...
  • Page 144 Chapter 4 System Assembly  Page: 141 PA-6222 SERIES USER S MANUAL...
  • Page 145 Chapter 4 System Assembly  Page: 142 PA-6222 SERIES USER S MANUAL...

  • Page 146: Exploded Diagram For Lcd & Touch Panel

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR LCD & TOUCH PANEL  Page: 143 PA-6222 SERIES USER S MANUAL...
  • Page 147 Chapter 4 System Assembly  Page: 144 PA-6222 SERIES USER S MANUAL...

  • Page 148: Exploded Diagram For Inside Case

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR INSIDE CASE  Page: 145 PA-6222 SERIES USER S MANUAL...
  • Page 149 Chapter 4 System Assembly  Page: 146 PA-6222 SERIES USER S MANUAL...

  • Page 150: Exploded Diagram For Msr

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR MSR  Page: 147 PA-6222 SERIES USER S MANUAL...
  • Page 151 Chapter 4 System Assembly  Page: 148 PA-6222 SERIES USER S MANUAL...

  • Page 152: Display

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR SECOND DISPLAY  Page: 149 PA-6222 SERIES USER S MANUAL...

  • Page 153: Exploded Diagram For Stand

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR STAND  Page: 150 PA-6222 SERIES USER S MANUAL...
  • Page 154 Chapter 4 System Assembly  Page: 151 PA-6222 SERIES USER S MANUAL...

  • Page 155: Exploded Diagram For Ppc Packing

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR PPC PACKING  Page: 152 PA-6222 SERIES USER S MANUAL...
  • Page 156 Chapter 4 System Assembly  Page: 153 PA-6222 SERIES USER S MANUAL...

  • Page 157: Exploded Diagram For Pos Packing

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR POS PACKING  Page: 154 PA-6222 SERIES USER S MANUAL...

  • Page 158: Exploded Diagram For Stand Packing

    Chapter 4 System Assembly EXPLODED DIAGRAM FOR STAND PACKING  Page: 155 PA-6222 SERIES USER S MANUAL...
  • Page 159 Chapter 4 System Assembly  Page: 156 PA-6222 SERIES USER S MANUAL...

Table of Contents
