Passphrase: To change the WPA passphrase of the WiFi channel, type the new value into the
field provided and click the Generate WPA PSK from Passphrase button. The length of the
passphrase must be between 8 and 63 characters inclusive.
Generate WPA PSK from Passphrase: This button generates the WPA key from the given
passphrase.
User Name: To change the WPA logon user name, type the new value into the field provided
and click the Submit Changes button.
Password: To change the WPA logon password for the given user, type the new value into the
field provided and click the Submit Changes button.
Submit Changes: This button updates all the configuration information entered on the current
web page and refreshes the display.
Reboot: This button performs a soft reboot of the main processor on the router. None of the
WiFi parameter changes will be put into effect until after a reboot. Take care when making
changes as an errant configuration may result in loss of communication and no access to the
configuration pages. The only way to restore communications may be to reset to factory
defaults.

2.9. 709 Setup Page

The 709 Setup Page is used to set up the 709.1 protocol specific properties of the router. This
information includes the subnet address, node address, domain address, node ID and node
state numbers for both sides of the router and the twin mode monitoring application (when
enabled) as well as the subnet and group forwarding tables. Following is a brief description of
each item listed on the page, as well as instructions on how to set or change items. The Page
has three views, one for Side A (IP), the second for Side B (FTT-10, and the third for the twin
mode application (when enabled). In Bridging Router mode both Side A and Side B are IP. The
main top section of the page looks like the following.
Fig.2.17:
709 Side B Setup Page Main Section
