Reboot: This button performs a soft reboot of the main processor on the router. This is needed
for any of the changes on this page to take effect. When rebooting the Rebooting page will be
displayed (see previous section).

2.8. Wi-Fi Setup Page

For eNodeIV devices equipped with WiFi IP interfaces the WiFi setup button will appear and will
display the WiFi setup page.
MODE: This displays the WiFi channel access mode of the router. To change the WiFi mode,
select the desired mode in the popup menu and then click the Submit Changes button. The
mode will not change until after a reboot. The Four possible modes are –
Any type, Infrastructure, Ad hoc (join or create), and Ad hoc (join only).
• Any Type: Will attempt to connect on each of access modes until it finds one with the
chosen SSID.
• Infrastructure: Use this mode for connecting to an access point.
• Ad hoc (join or create): Use this mode for creating an ad hoc network if one does not exist or
joining one that already exists with the chosen SSID
• Ad hoc (join only): Use this mode for joining an existing ad hoc network
SSID: To change the SSID of the WiFi channel, type the new value into the field provided and
click the Submit Changes button.
Channel: To change the WiFi channel number select it from the popup menu. To search for an
available channel, select Search. In search mode, the router will search all channels until it finds
one with the chosen SSID. Select the new value and click the Submit Changes button.
WEP: Select the appropriate radio button. The two choices are Enabled and Disabled. Select the
new value and click the Submit Changes button. WEP may not be enabled when WPA is enabled
and vice versa.
Default Key: WEP stores four different keys that may be used to join a WEP protected network.
Only one key is needed for any network . Select which key from the popup menu and click the
Submit Changes button.
KEY 0 - KEY3: To change the WEP Key of the WiFi channel, type the new value into the field
provided and click the Submit Changes button. The length of the key may be either 13 Hex
digits (for 64 bit encryption) or 26 Hex digits (for 128 bit encryption). The length needed is
determined by the access point or ad hoc network settings.
WPA: Select the appropriate radio button. The two choices are Enabled and Disabled. Select
the new value and click the Submit Changes button. WEP may not be enabled when WPA is
enabled and vice versa.
