2.1.3. Wi-Fi Setup in Windows XP

• Go to the network connections control panel. Right click wireless connection and select
properties.
• Select the general tab. Set the IP address to one that is in the same subnet as the
eNodeIV's default IP of 10.0.2.40 with a subnet mask of 255.255.255.0. For example you
could use 10.0.2.41.
• Go to network properties and select the connection tab. Select "manual connect" to an
available wireless network not automatically connect.
• In the main network connections control panel, create a new wireless network by selecting
"add new network". Use the following settings the network:
In the Association Tab set the following fields:
SSID: "Adept"
Network Auth: open
Data Encryption : Disabled
Check the "this is a computer to computer network (ad-hoc)" box.
In the Authentication Tab leave the settings at the defaults.
In the Connection Tab set the following:
Check the "connect when this network is in range" box.
• Click Ok, then Ok again to save the settings.
• After a minute or two the computer will automatically connect to the eNodeIV
• You can now access the eNodeIV's configuration web pages through a web browser using a
url of "http://10.0.2.40".
