Configuration; Local Configuration - Hoffer Flow Controls HIT-2A User Manual

5. CONFIGURATION

The HIT-2A is fully configurable, with all parameters being stored in
non-volatile memory.
The instrument may be configured using the front panel keys, a PC
running Terminal Emulation software, a ASCII terminal, or a PC
running the HIT-2A Configuration software.
5-1

Local Configuration

Local configuration is accomplished using the four buttons below the
display while viewing the configuration parameters on the display.
The local configuration mode is entered by pressing the
Once in the local configuration mode each of the four buttons have a
special purpose as detailed below.
Press to increment digit or
change selection.
Press to initiate selection
operation and to accept
selection.
Configuration
P
OK
19
button.
P
Press for next menu item.
Press to move cursor
one position to the right.
HP-306
