Model Number Designation
ENCLOSURE STYLE
INPUT POWER
LOOP POWERED ANALOG OUTPUT
OPTIONS
MOUNTING
SPECIAL FEATURES
ENCLOSURE STYLE
MODEL HIT-2A-(
A
( A )
OPTION
(2)
NEMA 4X ENCLOSURE, HIT-2A MOUNTED BEHIND CLEAR COVER.
(3)
EXPLOSION-PROOF ENCLOSURE.
(3A)
ATEX Exd ENCLOSURE, STANDARD BLUE.
(3B)
ENCLOSURE FOR BRAZIL, GRAY.
(P)
PANEL MOUNT - SURFACE MOUNTED ON CUSTOMER'S PANEL;
NO ENCLOSURE BEHIND PANEL ON HIT-2A.
(PD)
PANEL MOUNT ENCLOSURE WITH CLEAR DOOR AND LOCK.
NEMA 1 ENCLOSURE (
(4)
COVER FOR INDOOR/DRY INSTALLATION ONLY).
(5)
NEMA 4X ENCLOSURE/HIT2A ENCLOSURE (MOUNTED BEHIND CLEAR COVER
WITH SUNSHADE.)
(6)
EXPLOSION-PROOF ENCLOSURE WITH SUNSHADE.
(6A)
ATEX Exd ENCLOSURE, STANDARD BLUE WITH SUNSHADE.
INPUT POWER
MODEL HIT-2A-( )-(
( B )
OPTION
(A)
INTERNAL BATTERIES (TWO EACH).
THIS OPTION CAN NOT SUPPORT REDI-PULSE COILS.
(B)
8 TO 30 VDC EXTERNAL POWER.
(AC)
UNIVERSAL 100-240 VAC @ 0.15A 50/60 HZ.
(X)
ENTER (X) IF LOOP POWERED ANALOG OUTPUT OPTION
(C) OR (D) BELOW IS SELECTED.
LOOP POWERED ANALOG OUTPUT
MODEL HIT-2A-(
( C )
OPTION
(C)
LOOP POWERED 4-20MA OUTPUT (8 TO 30 VDC).
(D)
LOOP POWERED 4-20MA OUTPUT WITH INTERNAL BATTERIES.
MODEL HIT-2A
TOTALIZER/FLOW RATE INDICATOR
MODEL HIT-2A-(
)-(
)-(
)-(
)-(
HIT-2A MOUNTED TO THE OUTSIDE OF CLEAR
B
)-(
)-(
)-(
)-(
)-(
C
)-(
)-(
A
)-(
B
)-(
C
)-(
)
)-(
)
)-(
)
Introduction
)-(
D
)-(
E
)-(
F
)
HP-306
2
