Messages

Commands Supported By Communications Messages
Command Description/Allowed Data/Response
1
Clear Total
CL
"0" to "99999999"
"TOTAL
Tag Number
DN
"0" to "99999999"
"TAG NUM
The first three digits are the units code for total. Changing
these digits will change the TU settings.
Linearization
FC
"0" = Average K factor
"1" = Linearization table
"F C METHOD = AVG" for Average K factor
or
"F C METHOD = LIN" for Linearization table
K Factor Decimal Point Location
KD
"0" for 00000000.
"1" for 0000000.0 and all K Factors are less than
"2" for 000000.00and all K Factors are less than 999999.99,
"3" for 00000.000 and all K Factors are less than
"K-FAC DECL=(DATA)"
Average K Factor
AK
"0.001" to
"AVG KFAC
HP-306
Appendix B
= 0"
= (DATA)"
9999999.9, otherwise not allowed
otherwise not allowed
99999.999, otherwise not allowed
"99999.999" if KD = 3
"999999.99" if KD = 2
"9999999.9" if KD = 1
" 99999999" if KD = 0
=(DATA)"
- Communications
31
