OPTIONS
MODEL HIT-2A-(
( D )
OPTION
(L)
20 POINT LINEARIZATION.
(RR)
REMOTE RESET
(AL)
LOW ALARM* OPTO ISOLATED OPEN COLLECTOR.
(AH)
HIGH ALARM* OPTO ISOLATED OPEN COLLECTOR.
(HT)
HEATER; REQUIRES DC POWER INPUT OPTION.
*NOTE:
EITHER LOW OR HIGH ALARM IS AVAILABLE, NOT BOTH.
MOUNTING
MODEL HIT-2A-(
( E )
OPTION
(F)
NEMA 4X STYLE 2 ENCLOSURE MOUNTED ON TURBINE.
MUST BE USED WITH "X" RISER TURBINE OPTION.
(FHT)
8" LONG TEMPERATURE RISER FOR NEMA 4X STYLE 2
ENCLOSURE MOUNTED ON TURBINE. REQUIRED WHEN
FLUID TEMPERATURES EXCEED 140 DEG. F. USED WITH
"X" RISER TURBINE OPTION.
(FX)
EXPLOSION-PROOF STYLE 3 ENCLOSURES MOUNTED ON
TURBINE. MUST BE USED WITH "X" RISER TURBINE OPTION.
(FXHT)
8" LONG TEMPERATURE RISER FOR EXPLOSION-PROOF
STYLE 3 ENCLOSURES MOUNTED ON TURBINE. REQUIRED
WHEN TEMPERATURES EXCEEDS 140 DEG. F. USED WITH
"X" RISER TURBINE OPTION.
(NP)
NEMA 4X ENCLOSURE PIPE MOUNTING KIT, 2" PIPE OR SMALLER.
SPECIFY IF PIPE IS VERTICAL OR HORIZINTAL.
SPECIAL FEATURES
MODEL HIT-2A-(
( F )
OPTION
(CE)
CE MARK REQUIRED FOR EUROPE
(MIL) MIL-S-901D, "SHOCK TESTS, H.I. (HIGH IMPACT) SHIPBOARD
MACHINERY, EQUIPMENT, AND SYSTEMS, REQUIREMENTS FOR;"
DATED 17 MARCH 1989. MIL-STD-167-1, MECHANICAL VIBRATION
OF SHIPBOARD EQUIPMENT (TYPE I – ENVIRONMENTAL & TYPE II –
INTERNALLY EXCITED), 1 MAY 1974.
(SP)
ANY SPECIAL FEATURES THAT ARE NOT COVERED IN THE
MODEL NUMBER USE A WRITTEN DESCRIPTION OF THE -SP.
NOTES: 1. OPTO-ISOLATED OPEN COLLECTOR TRANSISTOR IS STANDARD WITH ALL UNITS.
2. A LOCAL RESET MAGNET IS STANDARD WITH ALL UNITS EXCEPT IF REMOTE
RESETOPTION IS SELECTED.
3. WINDOWS® BASED SETUP DISC AND, IF REQUIRED, 6 FT COMMUNICATION
CABLE. IF THREE OR MORE UNITS ARE ORDERED ON THE SAME PURCHASE
ORDER ONE SET IS SUPPLIED AT NO CHARGE.
SPARE
OMNICEL MODEL ER26500 OR EQUIVALENT; LITHIUM SIZE C,
BATTERIES 3.6V 8500 mAh (TWO BATTERIES ARE REQUIRED FOR
BATTERY POWERED UNITS. ONE BATTERY IS REQUIRED FOR ALL
OTHER POWER OPTIONS TO RETAIN TOTAL DISPLAY IF POWER
FAILS.
)-(
)-(
)-(
D
)-(
)-(
)-(
)-(
)-(
E
)-(
)-(
)-(
)-(
)-(
)
)-(
)
)-(
F
)
