Display
FLo u
NN in
00000.000
FL d
SAPLE
1
1.000
outLo
99.999
outHi
PuLSE S
oFF
PuLSE F
8
PASS
1234
unit LoC
no
ALArNN
oFF
100000.0
ALArN
Menu item
Option
SEC
Rate Units
Min
HrS
dAY
Rate Decimal Point location
Max Sample Time
1
to
80
Out Low
Out High
Pulse Scale
oFF
1
10
100
1
Pulse Frequency
2
4
8
0000
Password
to
9999
Lock Unit
Yes
No
Alarm Function
oFF
rAtE
tot
Alarm Out
Configuration
Description
Select RATE units.
Set Rate decimal point location.
Set maximum time in seconds to
sample the input frequency. Default
1.
Sets flow rate value for 4 mA
output.
Sets flow rate value for 20 mA
output.
Sets scale for pulse out. 1, 10, 100
units of total for one pulse out.
OFF- turns pulse out off.
Sets frequency of burst of pulse out.
(1, 2, 4, 8)
Sets 4-digit password. Default
0000.
Locks the unit.
Select Rate or Total for alarm
output. OFF- turns alarm function
off.
Sets value to activate the alarm
output. Default 99999.999
21
HP-306
