Hoffer Flow Controls HIT-2A User Manual page 41

Command Description/Allowed Data/Response
Total Decimal Point Location
TD
"0" for 00000000.
"1" for 0000000.0. If UA set to Total and AL is greater
"2" for 000000.00. If UA set to Total and AL is greater
"3" for 00000.000. If UA set to Total and AL is greater
"FLOW DEC L=(DATA)"
Rate Units
FM
"0" for seconds
"1" for minutes
"2" for hours
"3" for days
"FLOW UNITS=(DATA)"
Rate Decimal Point Location
RD
"0" for 00000.
"1" for 0000000.0 and AF (and AL if UA set to Rate) is less
"2" for 000000.00 and AF (and AL if UA set to Rate) is less
"3" for 00000.000 and AF (and AL if UA set to Rate) is less
"RATE DEC L=(DATA)"
Max Sample Time
NB
"1" to "80"
"MAX M TIME=(DATA)"
Out Low
LF
"0.000" to a maximum value of the Out High setting
"4mA FLOW
HP-306
Appendix B
than 9999999.9 it not allowed.
than 999999.99 it not allowed.
than 99999.999 it not allowed.
(DATA) shall be:
"SEC" for seconds
"MIN" for minutes
"HR " for hours
"DAY" for days
than 9999999.9, otherwise not allowed.
than 999999.99, otherwise not allowed.
than 99999.999, otherwise not allowed.
=(DATA)"
- Communications
33
