Display
CLEArtot
no
10000000
tA9
AuErAgE
FAC NN
00000.000
FAC d
1.000
A FAC
PointS
20
4999.981
Fr 01
1.000
FAC01
1.000
C FAC
tot unit
100
0000000.0
tot d
Menu item
Option
Clear Total
Yes
No
Tag Number
Linearization Method
Linear
Average
K-factor Decimal Point
Average K-factor
2
Number of Points
to
20
Frequency 1-20
0
to
5000
K-factor 1-20
Correction Factor
0.001
to
99999.999
Total Units
100 = GAL
110 = FT3
140 = LIT
150 = M3
180 = BBL
Total Decimal Point
Configuration
Description
Clears accumulated total and sets
TOTAL display to zero.
User defined 5-digit number.
(#####)
Sets the flow calculation method to
average K-factor or K-factor table.
Set K-factor decimal point location.
Enter average K-factor.
Sets the number of entries in the
linearization table.
Enter a frequency in Hz for each
entry in the table. Decimal point is
fixed.
Enter a k-factor in pulses/gal for
each entry in the table.
User defined number between 0.001
and 99999.999 to multiply flow and
total. Default 1.0.
Select Total units.
If custom is selected all indicators
are off. (gal, lit, ft3, m3, bbl,
custom)
Set Total decimal point location.
