K R A ME R E LE CT R O N IC S L T D .
USER MANUAL
MODEL:
MODULAR TBUS-3xl
Table Connection Bus
P/N: 2900-300062 Rev 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MODULAR TBUS-3xl and is the answer not in the manual?

Questions and answers

Related Manuals for Kramer MODULAR TBUS-3xl

Summary of Contents for Kramer MODULAR TBUS-3xl

  • Page 1 K R A ME R E LE CT R O N IC S L T D . USER MANUAL MODEL: MODULAR TBUS-3xl Table Connection Bus P/N: 2900-300062 Rev 2...

  • Page 3: Table Of Contents

    Contents Introduction Getting Started Achieving the Best Performance Glossary Overview Your TBUS-3xl Enclosure TBUS-3xl Optional Inner Frames TBUS-3xl Accessories Power Socket Options Power Cord Options Installing the TBUS-3xl Assembling the Inner Frame Installing the Inner Frame Cutting an Opening in the Table Inserting the TBUS-3xl through the Cut Out Opening Connecting the Cables Inserting Cables via the 4-cable Pass-through Insert...

  • Page 4: Introduction

    GROUP 9: Room Connectivity, GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Thank you for purchasing the Kramer TBUS-3xl enclosure, which is ideal for boardrooms, conference and training rooms! Note that the inner frame, power socket assembly, power cord and other inserts for the TBUS-3xl enclosure are purchased separately.

  • Page 5: Getting Started

    Use Kramer high-performance high-resolution cables Go to http://www.kramerelectronics.com to check for up-to-date user manuals, a complete list of Kramer wall plates and module connectors, application programs, and to check if firmware upgrades are available (where appropriate). Achieving the Best Performance To achieve the best performance: •...

  • Page 6: Overview

    Overview The Kramer TBUS-3xl is a high-quality, anodized aluminum, table-mounted connection bus enclosure for boardrooms and conference rooms. Its attractive enclosure is designed to provide maximum connectivity in the smallest possible footprint. The unit is sturdy, cost-effective, and easy to install.

  • Page 7: Your Tbus-3Xl Enclosure

    Your TBUS-3xl Enclosure Figure 2: TBUS-3xl Enclosure Top View Feature Function Black Anodized/Brushed Includes an opening for cable pass-through; covers the inner Clear Textured Lid frame, leaving the table surface neat and tidy Outer Rim Fits over the table surface. A protective rubber guard protects the outer rim during shipping.

  • Page 8: Tbus-3Xl Optional Inner Frames

    1 cable pass-through insert T3F-1C (P/N: 80-003199) 1 opening for 1 power socket 4-cable pass-through insert Custom made inner frames can be designed if required. Contact Kramer Electronics for more details. TBUS-3xl Accessories Accessories Description Inserts You can install any wall plate devices as well as any of the single or dual inserts—see our Web site for details.

  • Page 9: Power Socket Options

    Power Socket Options A choice of power sockets per inner frame are available in several versions, including power sockets for the USA, Germany (the Europlug), Belgium-France, Italy, South Africa, Israel and Australia. A “Universal” socket for general use is also available (see the compatibility restrictions in the table below).

  • Page 10: Power Cord Options

    Power Cord Options You can order any of the following power cords to use with a modular TBUS: Power Cord Type Description 6ft/110V (North America) C-AC/US (110V) 91-000099 6ft/125V (Japan) C-AC/JP (125V) 91-000699 6ft/220V (Europe) C-AC/EU (220V) 91-000199 6ft/220V (Israel) C-AC/IL (220V) 91-000999 6ft/250V (UK)

  • Page 11: Installing The Tbus-3Xl

    Installing the TBUS-3xl To install the TBUS-3xl perform the following steps: 1. Assemble the inner frame (see Section 5.1 2. Install the inner frame (see Section 5.2 3. Cut an opening in the table (see Section 5.3 4. Insert the unit through the opening and secure to the table (see Section 5.4 5.

  • Page 12: F Igure 3: Tbus-3Xl Inner Frame (P/N: 80-003099)

    1. Unscrew the two screws that fasten the blank plate to the inner frame and remove the blank plate. 2. Place the required Kramer insert over the opening, insert the two screws to fix the Kramer insert in place, and tighten them.

  • Page 13: Installing The Inner Frame

    Installing the Inner Frame To install the inner frame: 1. Place the inner frame inside the TBUS-3xl enclosure. 2. Set the required height using your fingers to bring the inner frame to the desired position, screw and tighten it in place using the height adjustment screws (supplied with the inner frame).

  • Page 14: Inserting The Tbus-3Xl Through The Cut Out Opening

    Take care not to damage the table. If needed, you can download a full-scale template from our Web site. Kramer Electronics is not responsible for any damage caused to the table. Inserting the TBUS-3xl through the Cut Out Opening To install TBUS-3xl in the opening: 1.

  • Page 15: Connecting The Cables

    Connecting the Cables When replacing blank inserts with connector inserts (for example, VGA, audio, HDMI and so on): 1. Insert the cables to their appropriate connectors from underneath. 2. Secure the cables to the tie holes on the TBUS-3xl. Do not secure the cables too tightly or too loosely. Leave a small amount of slack.

  • Page 16: Inserting The Pass-Through Cables

    Figure 6: 4-cable Pass-through Insert (P/N: 80-003199) Inserting the Pass-through Cables When replacing a blank insert with the pass-through insert, for example, to connect a laptop, do the following: 1. Remove the two screws attaching the split pass-through bracket. 2. Remove the split grommet. 3.

  • Page 17: Adjusting The Height Of The Inner Frame

    Adjusting the Height of the Inner frame If needed, you can adjust the inner frame height to accommodate large or bulky cables. To adjust, perform the following: 1. Remove the height adjustment screws, while supporting the surface from underneath with your fingers. 2.

  • Page 18: Using The Tbus-3Xl

    Using the TBUS-3xl Once the TBUS-3xl is installed, you can easily customize it to suit your own requirements by plugging in the required A/V equipment, as illustrated in the example in Figure Figure 7: TBUS-3xl Boardroom Installation TBUS-3xl - Using the TBUS-3xl...

  • Page 19: Technical Specifications Of The Assembled Tbus-3Xl

    Technical Specifications of the Assembled TBUS-3xl POWER SOURCE Power Socket Assemblies (AC power limits): Universal 100-240V AC, 50/60Hz, 5A Maximum 5A per power outlet Fully compatible with power plugs in the UK, India, Italy and Denmark, as well as with the 2-prong Europlug. Partially compatible (if the polarity is reversed) with plugs in China, Switzerland, Israel and the USA.
  • Page 20 TBUS-3xl...
  • Page 22 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
