- Page 1 KR AM E R E LE CT RO NI C S LT D. USER MANUAL MODEL: MODULAR TBUS-5xl Table Connection Bus P/N: 2900-300070 Rev 3...
-
Page 3: Table Of Contents
Contents Introduction Getting Started Achieving the Best Performance Glossary Overview Your TBUS-5xl Enclosure TBUS-5xl Optional Inserts TBUS-5xl Optional Inner Frames TBUS-5xl Accessories Power Socket Options Power Cord Options Installing the TBUS-5xl Assembling the Inner Frame Installing the Inner Frame Cutting an Opening in the Table Inserting the TBUS-5xl through the Cut Out Opening Connecting the Cables Inserting the Pass-through Cables... -
Page 4: Introduction
GROUP 9: Room Connectivity, GROUP 10: Accessories and Rack Adapters, and GROUP 11: Sierra Products. Thank you for purchasing the Kramer TBUS-5xl enclosure, which is ideal for boardrooms, conference and training rooms! Note that the inner frame, power socket assembly, power cord and other inserts for the TBUS-5xl enclosure are purchased separately. -
Page 5: Getting Started
Avoid interference from neighboring electrical appliances that may adversely influence signal quality Position your Kramer TBUS-5xl away from moisture, excessive sunlight and dust Glossary Inner frame The inner frame fits into the TBUS enclosure... -
Page 6: Overview
Overview The Kramer TBUS-5xl is a high-quality, anodized aluminum, table-mounted connection bus enclosure for boardrooms and conference rooms. Its attractive enclosure is designed to provide maximum connectivity in the smallest possible footprint. The unit is sturdy, cost-effective, and easy to install. -
Page 7: Your Tbus-5Xl Enclosure
Your TBUS-5xl Enclosure Figure 2: TBUS-5xl Enclosure Top View Feature Function Black Anodized/Brushed Includes an opening for cable pass-through; covers the inner Clear Textured Lid frame, leaving the table surface neat and tidy Outer Rim Fits over the table surface. A protective rubber guard protects the outer rim during shipping. -
Page 8: Tbus-5Xl Optional Inserts
T5F-13 (P/N: 80-004099) 1 opening for 1 power socket 2 blank inserts 1 cable pass-through insert Custom made inner frames can be designed if required. Contact Kramer Electronics for more details. TBUS-5xl Accessories Accessories Description Inserts You can install any wall plate devices as well as any of the single or dual inserts—see our Web site for details. -
Page 9: Power Socket Options
Power Socket Options Inner frames support installing one or more of the following power socket assemblies. Note: The Brazilian power sockets are supplied as dual power sockets in a single power socket assembly (see table below). 4.4.1 Single Power Socket Assemblies Socket Type Power Specs Universal:... - Page 10 Socket Type Power Specs Socket Type Power Specs Switzerland TS-1CH (80-000027) Brazil TS-BR (80-000034) 100-240V AC, 50/60Hz, 100-240V AC, 50/60Hz, 5A Maximum 5A/2.5A per power outlet Maximum 5A per power outlet 4.4.2 Dual Power Socket Assemblies Socket Type Power Specs TS-2U (80-001899) Universal 100-240V AC, 50/60Hz, 5A...
-
Page 11: Power Cord Options
Socket Type Power Specs South Africa: TS-2ZA (80-002599) 100-240V AC, 50/60Hz, 5A Maximum 5A/2.5A per power outlet Australia: TS-2AU (80-002499) 100-240V AC, 50/60Hz, 5A Maximum 5A/2.5A per power outlet Power Cord Options You can order any of the following power cords to use with a modular TBUS: Power Cord Type Description 6ft/110V (North America) -
Page 12: Installing The Tbus-5Xl
Installing the TBUS-5xl To install the TBUS-5xl perform the following steps: Section 5 1. Assemble the inner frame (see .1). Section 5 2. Install the inner frame (see .2). Section 5 3. Cut an opening in the table (see .3). -
Page 13: Figure 3: Tbus-5Xl Inner Frame (P/N: 80-004099)
1. Unscrew the two screws that fasten the blank plate to the inner frame and remove the blank plate. 2. Place the required Kramer insert over the opening, insert the two screws to fix the Kramer insert in place, and tighten them. -
Page 14: Installing The Inner Frame
Installing the Inner Frame To install the inner frame: 1. Place the inner frame inside the TBUS-5xl enclosure. 2. Set the required height using your fingers to bring the inner frame to the desired position, screw and tighten it in place using the height adjustment screws (supplied with the inner frame). -
Page 15: Inserting The Tbus-5Xl Through The Cut Out Opening
Take care not to damage the table. If needed, you can download a full-scale template from our Web site. Kramer Electronics is not responsible for any damage caused to the table. Inserting the TBUS-5xl through the Cut Out Opening To install TBUS-5xl in the opening: 1. -
Page 16: Connecting The Cables
Connecting the Cables When replacing blank inserts with connector inserts (for example, VGA, audio, HDMI and so on): 1. Insert the cables to their appropriate connectors from underneath. 2. Secure the cables to the tie holes using the included self-locking ties. Do not secure the cables too tightly or too loosely. -
Page 17: Adjusting The Height Of The Inner Frame
Adjusting the Height of the Inner Frame If needed, you can adjust the inner frame heights to accommodate large or bulky cables. To adjust, perform the following: 1. Remove the height adjustment screws, while supporting the surface from underneath with your fingers. 2. -
Page 18: Using The Tbus-5Xl
Using the TBUS-5xl Once the TBUS-5xl is installed, you can easily customize it to suit your own requirements by plugging in the required A/V equipment, as illustrated in the example in Figure Figure 6: TBUS-5xl Boardroom Installation TBUS-5xl - Using the TBUS-5xl... -
Page 19: Technical Specifications Of The Assembled Tbus-5Xl
Technical Specifications of the Assembled TBUS-5xl POWER SOURCE Power Socket Assemblies (AC power limits): Universal 100-240V AC, 50/60Hz, 5A Maximum 5A per power outlet Fully compatible with power plugs in the UK, India, Italy and Denmark, as well as with the 2-prong Europlug. Partially compatible (if the polarity is reversed) with plugs in China, Switzerland, Israel and the USA. - Page 21 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerav.com E-mail: info@kramerel.com SAFETY WARNING...
